M420 General Flux Vector Control Inverter User Manual Trouble Shooting
15
Display
Fault Name
Possible Causes
Solutions
Err33
Fast current
limit fault
1: The load is too heavy or the
rotor is locked.
2: The acceleration time is
too short.
1: Reduce the load, or
change the inverter with
larger power.
2: Increase the acceleration
time.
Err34
Load becoming
0
The detection is reached.
Get more details form F9-28 to
F9-30.
Reset the fault or reset
F9-28 to F9-30 value
Err35
Control power
supply fault
1: The input voltage is not within
the allowable range.
2:The power on and off is too
frequently.
1: Adjust the input voltage to
the allowable range.
2:Extension of power on
cycle.
Err37
Data storage
fault
Communication between DSP
and EEPROM fault.
1: Replace the main control
board.
2: Contact the agent or the
manufacturer for help.
Err39
Current running
time reached
Current running time of AC
driver is larger than .F7-38
value.
Reset the fault.
Err40
Accumulative
running time
reached
The accumulative running time
reaches the setting value of
F7-20.
Clear the record through the
parameter initialization
function or set F7-20 to a
new value.
Err42
Motor
switchover fault
during running
Change the selection of the
motor via terminal during
running of the AC drive.
Perform motor switchover
after the AC drive stops.
Err46
Master slave
control
communication
disconnection
1:There is no set host but set the
slave machine
2:The communication cable is
faulty or communication
parameter setting not correct.
1: Set host and reset the
fault.
2: Check the communication
cabling and communication
parameters F8.
