M420 General Flux Vector Control Inverter User Manual Function code Table
21
Function
Code
Parameter Name Setting Range Default
Property
F0-13 Rotation direction
0: Same direction
1: Reverse direction
2: Reverse forbidden
0
☆
F0-14
Maximum output
frequency
50.0Hz–1200.0 Hz(F0-20=1)
50.0Hz–600.00 Hz(F0-20=2)
50.00Hz
★
F0-15
Frequency source upper
limit
0: Set by F0-16
1: AI1
2: AI2
3: Communication setting
4: Pulse setting
0
★
F0-16 Frequency upper limit
Frequency lower limit(F0-18)to
maximum frequency (F0-14)
50.0Hz
☆
F0-17
Frequency upper limit
offset
0.00 Hz to maximum frequency
(F0-14).
0.00Hz
☆
F0-18
Frequency lower limit
0.00 Hz to frequency upper
limits (F0-16).
0.00Hz
☆
