Function Code Table M420 General Flux Vector Control Inverter User Manual
Function
Code
Parameter Name Setting Range Default
Property
time
F1-06
Startup DC braking
current/ Pre-excited
current
0%
～
100% 0%
★
F1-07
Startup DC braking time/
Pre-excited time
0.0s
～
100.0s 0.0s
★
F1-08
Acceleration/Deceleration
mode
0: Linear
1: S-curve
0
★
F1-09
Acceleration time
proportion of S-curve start
segment
0.00%～80.00%
20.00%
★
F1-10
Deceleration time
proportion of S-curve start
segment
0.00%～80.00%
20.00%
★
F1-11
Acceleration time
proportion of S-curve end
segment
0.00%～80.00%
20.00%
★
F1-12
Deceleration time
proportion of S-curve end
segment
0.00%～80.00%
20.00%
★
F1-13
Stop mode
0: Decelerate to stop
1: Coast to stop
0
☆
F1-14
Initial frequency of stop
DC braking
0.00HZ ～
maximum frequency
(F0-14)
0.00Hz
☆
F1-15
Waiting time of stop DC
braking
0.0s～100.0s
0.0s
☆
F1-16
Stop DC braking current
0%～100%
0%
☆
F1-17
Stop DC braking time
0.0s～36.0s
0.0s
☆
F1-21
Demagnetization time
0.01s～3.00s
0.50s
★
F1-23
Nonstop at instantaneous
stop (when power fail)
mode selection
0: Ineffective
1: Automatic start at power
fluctuation
0
★
