M420 General Flux Vector Control Inverter User Manual Function code Table
25
Function
Code
Parameter Name Setting Range Default
Property
2: Decelerate to stop.
F1-24
Deceleration time of
nonstop at instantaneous
stop
0.0s to 100.0s
10.0s
★
F1-25
Effective voltage of
nonstop at instantaneous
stop
60% to 85% 80%
★
F1-26
Recovery voltage of
nonstop at instantaneous
stop
85% to 100% 90%
★
F1-27
Detection time of
instantaneous stop
nonstop recovery voltage
0.0s to 300.0s 0.3s
★
F1-28
Auto-regulation gain of
nonstop at instantaneous
stop
0 to 100 40
☆
F1-29
Auto-regulation integral
time of nonstop at
instantaneous stop
1 to 100 20
☆
Group F2:
V/F Control Parameters
F2-00 V/F curve setting
0: Linear V/F.
1: Multi-point V/F.
2: Square V/F.
3: 1.7-power V/F.
4: 1.5-power V/F.
5: 1.3-power V/F.
6: Voltage and frequency
complete separation.
7: Voltage and frequency half
separation.
0
★
F2-01 Torque boost 0.0%
～
30.0%
0.0%
☆
F2-02
Cut-off frequency of
torque boost
0.00 Hz to maximum output
frequency (F0-14).
25.00Hz
★
