Function Code Table M420 General Flux Vector Control Inverter User Manual
Function
Code
Parameter Name Setting Range Default
Property
F2-03
Multi-point V/F
frequency 1 (F1)
0.00Hz to F2-05 3.00Hz
★
F2-04
Multi-point V/F voltage 1
(V1)
0.0% to 100.0% 8.0%
★
F2-05
Multi-point V/F
frequency 2 (F2)
F0-05 to F2-07 10.00Hz
★
F2-06
Multi-point V/F voltage 2
(V2)
0.0% to 100.0% 20.0%
★
F2-07
Multi-point V/F
frequency 3 (F3)
0.00Hz to 50.00Hz 50.00Hz
★
F2-08
Multi-point V/F voltage 3
(V3)
0.0% to 100.0% 100.0%
★
F2-09 Slip compensation ratio 0.0% to 200.0% 50.0%
☆
F2-10 Over-excitation gain 0 to 200 100
☆
F2-11
Oscillation suppression
gain
0 to 100
Model
dependent
☆
F2-13
Slip compensation time
0.02s to 1.00s 0.30s
☆
F2-15
Output voltage source for
voltage and frequency
separation
0: Digital setting (F2-16).
1: AI1 2: AI2
3: Multi-reference
4: Simple PLC 5: PID
6: Communication setting.
7: Pulse setting (DI5).
100.0% correspon
ds to the
rated.
0
☆
F2-16
Voltage digital setting for
V/F separation
0 V to rated motor voltage 0V
☆
F2-17
Voltage rise time of V/F
separation
0.0s to 3000.0s 1.0s
☆
F2-18
Voltage decline time of
0.0s to 3000.0s 1.0s
☆
