M420 General Flux Vector Control Inverter User Manual Function code Table
27
Function
Code
Parameter Name Setting Range Default
Property
V/F separation
F2-19
Stop mode selection upon
V/F separation
0: Frequency and voltage
declining independently.
1: Frequency declining after
voltage declines to 0.
0
☆
Group F3:
Vector Control Parameters
F3-00 Switchover frequency 1 1.00Hz to F3-02 5.00Hz
☆
F3-02 Switchover frequency 2 F3-00 to F0-14 10.00Hz
☆
F3-04
Speed loop proportional
gain at low frequency
1.0 to 10.0
4.0
☆
F3-05
Speed loop integral time
at low frequency
0.01s to 10.00s
0.50s
☆
F3-06
Speed loop proportional
gain at high frequency
1.0 to 10.0
2.0
☆
F3-07
Speed loop integral time
at high frequency
0.01s to 10.00s
1.00s
☆
F3-08
Speed loop integral
property
0
：
Integral take effect
1
：
Integral separation
0
★
F3-11
Torque adjustment
proportional gain Kp
0 to 30000
2200
☆
F3-12
Torque adjustment
integral gain Ki
0 to 30000
1500
☆
F3-13
Excitation adjustment
proportional gain Kp
0 to 30000
2200
☆
F3-14
Excitation adjustment
integral gain Ki
0 to 30000
1500
☆
F3-15
Flux braking gain 0 to 200
0
☆
F3-16
Field weakening torque
correction ratio
50% to 200%
100%
☆
F3-17
Slip compensation gain
50% to 200%
100%
☆
