Function Code Table M420 General Flux Vector Control Inverter User Manual
Function
Code
Parameter Name Setting Range Default
Property
F3-18
Speed loop feedback filter
time
0.000s to 1.000s 0.015s
☆
F3-19
Speed loop output filter
time
0.000s to 1.000s
0.000s
☆
F3-20
Source of power-driven
torque upper limit
0: F3-21
1: AI1 2: AI2
3: Communication setting
4: Pulse setting (DI5)
(Analog range corresponds toF3-21)
0
☆
F3-21
Power-driven torque
upper limit
0.0% to 200.0%
150.0%
☆
F3-22
Upper limit source of
braking torque
0: F3-23
1: AI1 2: AI2
3: Communication setting
4: Pulse setting (DI5)
(Analog range corresponds to
F3-23)
0
☆
F3-23
Braking torque upper
limit
0.0% to 200.0%
150.0%
☆
Group F4:
Motor 1Parameters
F4-00
Auto-tuning selection
0: No auto-tuning
1: Static auto-tuning
2: Complete auto-tuning
0
★
F4-01
Rated motor 1 power 0.1kW to 1000.0kW
Model
dependent
★
F4-02
Rated motor 1 voltage 0V to 1500V
380
★
F4-03
Number of pole pairs of
motor 1
2 to 64
Model
dependent
○
F4-04
Rated motor 1 current
0.01A to 600.00 A (motor rated
power ≤30 kW).
F4-01
dependent
★
