M420 General Flux Vector Control Inverter User Manual Function code Table
29
Function
Code
Parameter Name Setting Range Default
Property
0.1A to 6000.0 A (motor rated
power >30kW).
F4-05
Rated motor frequency 0.01Hz to F0-14
50.00Hz
★
F4-06
Rated motor 1 rotational
speed
0rpm to 60000rpm
F4-01
dependent
★
F4-07
Motor 1 no-load current
0.01A to F4-04 A (motor rated
power ≤30 kW).
0.1A to F4-04 A (motor rated
power >30kW).
Model
dependent
★
F4-08 Motor 1 stator resistance 0.001Ωto 65.535Ω
Model
dependent
★
F4-09 Motor 1 rotor resistance 0.001Ωto 65.535Ω
Model
dependent
★
F4-10 Motor 1 mutual inductive 0.1mH to 6553.5mH
Model
dependent
★
F4-11 Motor 1 leakage inductive 0.01mH to 655.35mH
Model
dependent
★
F4-12
Acceleration time of
complete auto-tuning
1.0s to 6000.0s
10.0s
☆
F4-13
Deceleration time of
complete auto-tuning
1.0s to 6000.0s
10.0s
☆
Group F5:
Input Terminals
F5-00 DI1 function selection
0: No function
1: Forward RUN (FWD)
2: Reverse RUN (REV)
3: Three-wire control
4
：
Forward JOG (FJOG)
5
：
Reverse JOG (RJOG)
6
：
Speed increase
1
★
F5-01 DI2 function selection 2
★
F5-02 DI3function selection 9
★
F5-03 DI4 function selection 12
★
F5-04 DI5 function selection
13
★
