Function Code Table M420 General Flux Vector Control Inverter User Manual
Function
Code
Parameter Name Setting Range Default
Property
F5-05 DI6 function selection
7
：
Speed Decrease
8
：
Coast to stop
9
：
Fault reset (RESET)
10
：
RUN pause
11
：
External fault normally
open (NO) input.
12
：
Constant speed 1
13
：
Constant speed 2
14
：
Constant speed 3
15
：
Constant speed 4
16
：
Terminal 1 for acceleration/
13
★
F5-06 DI7 function selection
13
★
