M420 General Flux Vector Control Inverter User Manual Function code Table
31
Function
Code
Parameter Name Setting Range Default
Property
deceleration time selection
17
：
DI for acceleration/
deceleration time selection
18
：
Frequency source
switchover
19
：
MOTPOT s
etting clear
(terminal, keypad)
20
：
Command source
switchover terminal 1
21
：
Acceleration/Deceleration
prohibited
22
：
PID pause
23
：
PLC status reset
24
：
Swing pause
25
：
Timer trigger input
26
：
Immediate DC injection
braking
27
：
External fault normally
closed (NC) input
28
：
Counter input
29
：
Counter reset
30
：
Length count input
31
：
Length reset
32
：
Torque control prohibited.
33
：
Pulse input
(enabledonlyforDI5).
34
：
Frequency modification
forbidden.
35
：
PID action direction
reverse.
36
：
ExternalSTOPterminal1.
37
：
Command source
switchover terminal 2
38
：
PID integral disabled
39
：
Switchover between main
