Trouble Shooting M420 General Flux Vector Control Inverter User Manual
3.1.1. Description of Function LED Indicator
LED Symbol Unit Implication Color
Unit LED
Hz Freq. Unit LED on— current parameter is frequency
value
Green
A Current Unit LED on— current parameter is current value Green
V Voltage Unit LED on— current parameter is voltage value Green
RPM
(Hz+A)
Speed Unit LED on —current parameter is rotation speed
value
Green
%
(Hz+V )
Percentage LED on—
current parameter is percentage
value
Green
Function LED
RUN running status
LED
LED on—in the status of running
Light off—in the status of stop
LED flash—in the status of sleep
Green
L/D/C control mode
LED
LED off—
in the status of keyboard control
mode
LED on—
in the status of terminal control
mode
LED flash—in th
e status of remote
communication control mode
Red
FWD/RE
V
running
direction LED
LED off—in the status of forward rotation
LED on—in the status of reverse rotation
LED flash—the target frequency is opposite to
the actual frequency or in the status of
reverse-run prohibition
Red
TUNE/T
C
tuning/torque
/fault LED
LED on—in the status of torque control
LED flash—tuning/fault
Red
3.1.2. LED display
Five digits LED is able to display setup frequency, output frequency, various monitoring data
and alarm code. Function codes are usually displayed as decimal digits. For example, function
code F0-11 is displayed as “50.00”, means decimal digit “50”. When the function codes are
displayed as hexadecimal digits, the highest bit is “H.”, means present function code value is
displayed in hexadecimal way. For example, when function code F7-29 is displayed as “H.003F”,
the value of F7-29 is hexadecimal number”0x3f”
The user can freely set the monitoring data of stop and running status by the function code
F7-29/F7-30, all the details are showed as function code F7-29/F7-30.
