Function Code Table M420 General Flux Vector Control Inverter User Manual
Function
Code
Parameter Name Setting Range Default
Property
F5-37
DI2 On delay time 0.0s to 3600.0s
0.0s
☆
F5-38
DI2 Off delay time 0.0s to 3600.0s
0.0s
☆
F5-39
DI3 On delay time 0.0s to 3600.0s
0.0s
☆
F5-40
DI3 Off delay time 0.0s to 3600.0s
0.0s
☆
F5-41
AI1 function selection as
DI terminal
0 to 53 as DI terminal function.
0
★
F5-42
AI2 function selection as
DI terminal
0 to 53 as DI terminal function.
0
★
F5-44
AI effective mode
selection as DI terminal
Unit's digit(AI1).
0: High level effective.
1: Low level effective.
Ten's digit(AI2).
0: High level effective.
1: Low level effective.
Hundred’s digit::reserved
00
☆
F5-45 AI curve selection
Unit's digit
(AI1 curve selection)
0: 2 points curve.
1: Multi-point curve 1.
2: Multi-point curve 2.
Ten's digit
(AI2 curve selection).
0: 2 points curve
1: Multi-point curve 1
2: Multi-point curve 2
Hundred’s digit: reserved
00
☆
F5-46
AI Signal input type
selection
Unit’s digit:AI1;
Ten’s digit:AI2
00
☆
