Scarlett SC-1149 [4/16] Gb instruction manual

www.scarlett-europe.com SC-1149 4

GB INSTRUCTION MANUAL

IMPORTANT SAFEGUARDS

· Before the first connecting of the appliance check that voltage indicated on the rating label corresponds to the mains voltage in your home.

· For home use only. Do not use for industrial purposes. Do not use the appliance for any other purposes than described in this instruction

manual.

· Do not use outdoors.

· Do not disassemble the appliance when it is plugged to the power supply. Always unplug the appliance from the power supply before

cleaning and when not in use.

· To prevent risk of electric shock and fire, do not immerse the appliance in water or in any other liquids. If it was happened, unplug it

immediately and check in service center.

· Close supervision is necessary when it is used near children.

· Do not leave the appliance switched on when not in use.

· Do not use other attachments than those supplied.

· Do not operate after malfunction or cord damage.

· Do not attempt to repair, adjust or replace parts in the appliance. Check and repair the malfunctioning appliance in the nearest service center

only.

· Keep the cord away from sharp edges and hot surfaces.

· Do not pull, twist, or wrap the power cord around appliance.

· Do not place the appliance near gas or electric oven or store at heated surface.

· Avoid contacting with moving parts.

· The blades are very sharp, so handle them with care.

· Do not push products into the appliance by fingers while it is in operation. If food becomes lodged in feeder tube, use pusher to push it down.

If this doesnt work, turn the motor off, unplug unit, and then disassemble appliance to remove remaining food.

· When carrying the unit be sure to hold the motor housing with both hands. Do not carry the unit by the hopper plate or head.

· Do not fix the cutting blade and cutting plate when using KEBBE attachment.

· Do not grind hard food such as bones, nuts, ginger or other products with hard fiber.

· When the circuit breaker activates, do not switch on.

· Do not run meat grinder continuously for longer than 15-20 minutes. Turn off switch and let it rest for at least 10 minutes to cool down

the motor, otherwise the motor may be damaged.

· Be sure to turn switch off appliance after each use. Make sure the motor stops completely before disassembling.

· Do not overload appliance with a products.

· BEFORE THE FIRST USING

· Wash all parts (except body) in warm soapy water.

· Before plugging in, ensure the appliance is switched off.

INSTRUCTION FOR USING

ASSEMBLING

· Place the head tightly onto the head inlet. Holding the head with one hand, pull down the head stopper into the hole on the side of the motor

housing and snap it clockwise (fig.1).

· Place the snake into the head, long end first, and turn to feed the screw slightly until it is set into the motor housing (fig.2).

· Place the cutting blade onto the snake shaft with the blade facing the front as illustrated (fig.3). Place the desired cutting plate next to the

cutting blade, fitting protrusions in the slots (fig.4). If it is not fitted properly, meat will not be ground.

· Screw the fixing ring tightly (fig.5). Do not over tighten.

· Place the hopper plate on the head and fix it into position.

· Locate the unit on a firm place.

· The air passage at the bottom and the side of the motor housing should be kept free and not blocked.

MINCING MEAT

· Cut all foods into pieces so that they pass easily into the hopper opening.

· Plug the unit on and switch it on.

· Feed foods onto the hopper plate. To feed it use the food pusher only (fig.6).

· After use switch the unit off and unplug it from the power supply.

REVERSE FUNCTION

· In case of jamming switch off the appliance and switch reverse knob.

· Snake will be rotating in the opposite direction, and the head will get empty.

· If it doesnt work, switch off the unit and clean it.

CLEANING AND MAINTENANCE

DISASSEMBLING

· Switch off the appliance and make sure that the motor has stopped completely.

· Unplug the appliance.

· Disassemble by reversing the steps from 1-5 pictures.

· Fixing ring has pins for easy unscrewing (fig.7).

· To remove the cutting plate easily, place a screwdriver between the cutting plate and the head as illustrated and lift it up (fig.8).

CLEANING

· Remove meat, etc.

· Wash each part in warm soapy water.

· Do not use abrasives, chlorine containing substances or organic solvents.

· Do not immerse the motor housing in water, but only wipe it with a damp cloth.

· Wipe all the cutting parts with vegetable oil.

STORAGE

· Switch off and unplug the appliance; let it entirely cool.

· Complete all requirements of Chapter CLEANING AND MAINTENANCE.

· Reel on the power cord.

· Keep the appliance in a dry cool place.
