Chapter 11 Description of Parameter Settings|C200 Series
11-14
external terminal is OFF, the drive won’t receive any operation signal and can’t execute JOG.
Digital Keypad STOP Function
Factory Setting: 0
Settings 0: STOP key disable
1: STOP key enable
~
Reserved
Display Filter Time (Current)
Factory Settings: 0.100
Settings: 0.001~65.535 sec
Set this parameter to minimize the current fluctuation displayed by digital keypad.
Display Filter Time (Keypad)
Factory Settings: 0.100
Settings: 0.001~65.535 sec
Set this parameter to minimize the display value fluctuation displayed by digital keypad.
Software Version (date)
Factory Settings: ####
Settings: Read only
This parameter displays the drive’s software version by date.
