en
13
Note
During super freezing the refrigerator
compartment becomes a little colder.
Switching on and off
Fig. "
Keep pressing the temperature selection
button 4 until the Super display 3 is lit.
Super freezing automatically switches off
after approx. 2½ days.
Thawing frozen food
Depending on the type and application,
select one of the following options:
■ at room temperature
■ in the refrigerator
■ in an electric oven, with/without fan
assisted hot-air
■ in the microwave
m Caution
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Interior fittings
You can reposition the shelves inside
the appliance and the door shelves as
required:
■ To do this, pull out shelf, lift at the front
and take out. Fig. (
■ Raise the door shelf and remove.
Fig. )
Chiller compartment
Fig. !/6
The chiller compartment has lower
temperatures than the refrigerator
compartment. Even temperatures below
0 °C may occur.
Ideal for storing fish, meat and sausage.
Not suitable for lettuce and vegetables
and produce sensitive to cold.
Bottle shelf
Fig. %
Bottles can be stored securely on
the bottle shelf. The holder can be
adjusted.
Ice cube tray
Fig. '
1. Fill the ice cube tray ¾ full of drinking
water and place in the freezer
compartment.
2. If the ice tray is stuck to the freezer
compartment, loosen with a blunt
implement only (spoon-handle).
3. To loosen the ice cubes, twist the ice
tray slightly or hold briefly under
flowing water.
Freezer calendar
Fig. !/13
To prevent the quality of the frozen food
from deteriorating, do not exceed the
storage duration. The storage period
depends on the type of produce.
The figures next to the symbols indicate
the permitted storage period
of the produce in months. In the case
of commercially available frozen food
observe the date of manufacture or use-
by date.
