1 Emotron AB 01--4965--01r1
Emotron CDU/CDX 2.0 Variable speed drives for Compact Drives
Electrical specifications related to model
* Available for a limited time and as long as drive temperature permits.
Table 1 Typical motor power at mains voltage 400 V
Model
Max. output
current [A]*
Normal duty
(120 %, 1 min every 10 min)
Heavy duty
(150 %, 1 min every 10 min)
Frame size
CDU CDX
Power @ 400 V
[kW]
Rated current
[A]
Power @ 400 V
[kW]
Rated current
[A]
CDU/CDX 48-008 9.0 11.3 3 7.5 2.2 6.0
B
CDU/CDX 48-010 11.4 14.3 4 9.5 3 7.6
CDU/CDX 48-013 15.6 19.5 5.5 13.0 4 10.4
CDU/CDX 48-018 21.6 27.0 7.5 18.0 5.5 14.4
CDU/CDX 48-026 31 39 11 26 7. 5 21
C
CDU/CDX 48-031 37 46 15 31 11 25
CDU/CDX 48-037 44 55 18.5 37 15 29.6
CDU/CDX 48-046 55 69 22 46 18.5 37
Table 2 Typical motor power at mains voltage 460 V
Model
Max. output
current [A]*
Normal duty
(120 %, 1 min every 10 min)
Heavy duty
(150 %, 1 min every 10 min)
Frame size
CDU CDX
Power @ 460 V
[hp]
Rated current
[A]
Power @ 460 V
[hp]
Rated current
[A]
CDU/CDX 48-008 9.0 11.3 3 7.5 3 6.0
B
CDU/CDX 48-010 11.4 14.3 5 9.5 3 7.6
CDU/CDX 48-013 15.6 19.5 7. 5 13.0 5 10.4
CDU/CDX 48-018 21.6 27.0 10 18.0 7.5 14.4
CDU/CDX 48-026 31 39 15 26 10 21
C
CDU/CDX 48-031 37 46 20 31 15 25
CDU/CDX 48-037 44 55 25 37 20 29.6
CDU/CDX 48-046 55 69 30 46 25 37
Table 3 Typical motor power at mains voltage 525 V
Model
Max. output
current [A]*
Normal duty
(120 %, 1 min every 10 min)
Heavy duty
(150 %, 1 min every 10 min)
Frame size
CDU CDX
Power @ 525 V
[kW]
Rated current
[A]
Power @ 525 V
[kW]
Rated current
[A]
CDU/CDX 52-008 9.0 11.3 4 7. 5 3 6.0
B
CDU/CDX 52-010 11.4 14.3 5.5 9.5 4 7.6
CDU/CDX 52-013 15.6 19.5 7.5 13.0 5.5 10.4
CDU/CDX 52-018 21.6 27.0 11 18.0 7.5 14.4
CDU/CDX 52-026 31 39 15 26 11 21
C
CDU/CDX 52-031 37 46 18.5 31 15 25
CDU/CDX 52-037 44 55 22 37 18.5 29.6
CDU/CDX 52-046 55 69 30 46 22 37
