2. Load a disc inside and then close the CD door. After that, reading TOC will start.
To play the disc
1. Press the FOLDER UP or DN buttons (4)/(5) or (28)/(36) to select desired folder. Total tracks of select'
ed folder will then be shown.
To pause the playing
Press the PLAY/PAUSE button during the disc is playing, the playing symbol will be flash.
Note: Press the PLAY/PAUSE button again to cancel pause function.
To stop the disc playing
Press STOP button (11 )/(29).
PLAY MODE for Repeat Track/Folder and Random Play Operation
1. Press PLAY MODE button (18) or (30) once for "current track repeat.
2. Press PLAY MODE button (18) or (30) twice for tracks in current folder repeat.
2. Press CD SKIP >^t I I** buttons (14)/(33) to select desired track.
3. Press the PLAY/PAUSE button (13)/(35) to start playing.
3. Press PLAY MODE button (18) or (30) third for tracks in all folder repeat.
4. In stop mode only, press PLAY MODE button (18) or (30) fourth for tracks in random play mode.
Note: Once your desired mode selected, press PLAY/PAUSE button (13)/(35) to start playback from stop
mode.
5. In stop mode, press the PLAY MODE button (18) or (30) fifth for cancel above modes.
PROGRAMMED PLAYBACK
The CD player enables you to program up to 20 tracks in a sequence of your choice. First select CD stop
mode.
1. Press the PROGRAM button (15) or (34) one time.
2. Pressing PROGRAM button again, then track 4 of folder 3 is stored.
Press the FOLDER UP or DN buttons (4) or (5)/ (28) or (36) to select desired folder.
3. Press the CD SKIP buttons (14) or (33) to select the desired track to be programmed.
4. Continue to program, repeat steps 2 and 3.
Reviewing programs
Press the PROGRAM button repeatedly. The track number programmed on each program number will be
displayed.
5. Pressing PLAY/PAUSE button (13)/(35) to play the program tracks.
Note: Press the PROGRAM button (if programmed tracks still exist) then PLAY/ PAUSE button, the pro
gram play will start again.
Clear the program
Press PROGRAM button in stop mode to review program tracks, then press the STOP button (11)/ (29) in
order to cancel the preset programs ("000" appears when pressing Program button again). (Or open the
CD door or change function to other mode)
PLAYING CASSETTE TAPE PLAYBACK
1. Press the POWER button (9)/(31) to turn on the system. The LCD display (12) illuminate. Select TAPE
mode by Function button.
2. Press STOP/EJECT key (21) to open the cassette door. Insert a prerecorded tape with exposed tape
downwards and full spool to the left, closed the cassette door.
3. To playback, press down the PLAY button (21).
4. To stop Playback, press down the STOP/ EJECT key (21).
To suspend playback
Press down PAUSE key (21).
ПЕРЕДНЯЯ ЧАСТЬ МАГНИТОЛЫ
ВЕРХНЯЯ ЧАСТЬ МАГНИТОЛЫ
22. Дверца / Ячейка для CD
23. Крышка дверцы CD
ЗАДНЯЯ ЧАСТЬ МАГНИТОЛЫ
24. Гнездо для громкоговорителя
Для подсоединения громкоговорителей (Л и П)
25. Провод'антенна для FM
26. Входная розетка переменного тока ' Для
подсоединения провода к сети переменного тока
27. Переключатель напряжения (по выбору)
ПУЛЬТ ДИСТАНЦИОННОГО УПРАВЛЕНИЯ
28. Кнопка FOLDER DN/MEM'DN
' Нажимая ее, Вы сможете "перелистывать" папки
диска в формате МР3 / заранее настроенные радиостанции
вниз по списку
29. Кнопка CD STOP/BAND (ОСТАНОВКА
ВОСПРОИЗВЕДЕНИЯ CD / ДИАПАЗОН)
' приостановка воспроизведения CD / отмена
предыдущей программы воспроизведения CD'треков
' выбор диапазона приема
30. Кнопка PLAY MODE (РЕЖИМ
ВОСПРОИЗВЕДЕНИЯ) ' для CD
Функция повтора/Беспорядочного воспроизведения CD'
треков.
31. Кнопка POWER ' СЕТЬ
8 13
РУССКИЙENGLISH
1. Кнопка BAND (ДИАПАЗОН)
Предназначается для выбора желаемого
диапазона приема.
2. Кнопка FUNCTION (ФУНКЦИЯ)
Предназначается для выбора режима работы:
CD/TUNER/ TAPE (Компакт'диск/тюнер
(радио)/кассета)
3. Гнездо для наушников (3.5 мм) Подсоедините
стереонаушники для индивидуального
прослушивания.
4. Кнопка FOLDER DN/MEM'DN ' Нажимая ее, Вы
сможете "перелистывать" папки диска в формате
МР3 / заранее настроенные радиостанции вниз
по списку
5. Кнопка FOLDER UP/MEM'UP ' Нажимая ее, Вы
сможете "перелистывать" папки диска в формате
МР3 / заранее настроенные радиостанции вверх
по списку
6. Встроенный микрофон
7. Колонка громкоговорителя (Л)
8. STANDBY ' Индикатор РЕЖИМА ОЖИДАНИЯ
9. Кнопка POWER ' СЕТЬ
Кнопка СЕТЬ (включение/выключение) позволяет
включить систему либо перевести ее в режим
ожидания
10. Сенсор дистанционного управления
11. Кнопка CD STOP ' остановка воспроизведения
компакт'диска (CD) либо отмена предыдущей
программы воспроизведения CD'треков
12. ЖКД (жидкокристаллический дисплей)
проигрывателя CD / тюнера (радио)
13. Кнопка W I CD PLAY/PAUSE
Начало воспроизведения CD / приостановка
воспроизведения CD
14. Кнопка TUNING/CD SKIP ' Ручная настройка на
радиостанцию (вперед / назад), операция поиска
установленной станции 'выбор названия CD
(вперед / назад), операция поиска CD
15. Кнопка PROGRAM (ПРОГРАММА) ' память тюнера
' программа воспроизведения CD'треков
16. Кнопка VOLUME UP/DOWN (ГРОМЧЕ / ТИШЕ)
Используется для увеличения / уменьшения
громкости звука
17. Колонка громкоговорителя (П)
18. Кнопка PLAY MODE (РЕЖИМ
ВОСПРОИЗВЕДЕНИЯ) ' для CD
Функция повтора/Беспорядочного
воспроизведения CD'треков
19. Кнопка BBS
Нажав эту кнопку, вы обогатите звучание низкими
частотами
20. Дверца / Ячейка для кассеты
21. Кнопки управления воспроизведением кассет:
REC/PLAY/REW/F.FWD/ST'EJ/PAUSE (ЗАПИСЬ /
ВОСПРОИЗВЕДЕНИЕ / ПЕРЕМОТКА НАЗАД /
ПЕРЕМОТКА ВПЕРЕД ' ВЫБРОС КАССЕТЫ /
ОСТАНОВКА
VT-3496.qxd 25.09.03 11:07 Page 16
