English
10
Lens dimensions
Optional Lens (Wide Fix: LS2ST3)
LS2ST3, Wide Fix lens
316.9
334.4
Optional Lens (Wide Zoom: LS2ST1)
LS2ST1, Wide Zoom lens
316.9
413.9
Optional Lens (Standard: LS2SD)
LS2SD, Standard lens
316.9
349.0
