Product information
PX9210 Formulas:
Denitions:
W = Image Width
H = Image Height (size)
C = Throw distance
4:3 Screen Formulas:
W = H x 4/3
H = W x 3/4
Diagonal = W x 5/4
PX9210
Part Number
5J.JDH37.001 5J.JDH37.011 5J.JDH37.021 5J.JDH37.031
Throw Ratio
LS2ST3
(Wide Fix Lens)
LS2ST1
(Wide Zoom Lens)
LS2SD
(Standard Lens)
LS2LT1
(Semi Long Lens)
0.8 1.14-1.35 1.6-2.0 2.0-3.0
Diagonal Width Height (B) N/A Wide Tele Wide Tele Wide Tele
(inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m)
80 2.03 64 1.63 48 1.22 51 1.3 73 1.85 86 2.18 102 2.6 128 3.25 128 3.25 192 4.88
100 2.54 80 2.03 60 1.52 64 1.63 91 2.32 107 2.72 128 3.25 160 4.06 160 4.06 240 6.1
120 3.05 96 2.44 72 1.83 77 1.95 109 2.78 129 3.27 154 3.9 192 4.88 192 4.88 288 7.32
150 3.81 120 3.05 90 2.29 96 2.44 137 3.47 161 4.08 192 4.88 240 6.1 240 6.1 360 9.14
200 5.08 160 4.06 120 3.05 - - 182 4.63 214 5.45 256 6.5 320 8.13 320 8.13 480 12.19
300 7.62 240 6.1 180 4.57 - - 274 6.95 322 8.17 - - - - 480 12.19 720 18.29
400 10.16 320 8.13 240 6.1 - - - - - - - - - - 640 16.26 960 24.38
500 12.7 400 10.16 300 7.62 - - - - - - - - - - - - - -
Part Number
5J.JDH37.041
Throw Ratio
LS2LT2
(Long Zoom Lens)
3.11-5.18
Diagonal Width Height (B) Wide Tele
(inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m)
80 2.03 64 1.63 48 1.22 199 5.06 332 8.42
100 2.54 80 2.03 60 1.52 249 6.32 414 10.53
120 3.05 96 2.44 72 1.83 299 7.58 497 12.63
150 3.81 120 3.05 90 2.29 373 9.48 622 15.79
200 5.08 160 4.06 120 3.05 498 12.64 829 21.05
300 7.62 240 6.1 180 4.57 746 18.96 1243 31.58
400 10.16 320 8.13 240 6.1 - - - -
500 12.7 400 10.16 300 7.62 - - - -
