CHV190 series special inverter for crane
- 152 -
Parameter
description
Address
Meaning of value
R/W
feature
Reserved 2002H W
Reserved 2003H W
Torque
reference setting
2004H
Communication setting range
(-10000~10000).
Note:the value(-100.00%~100.00%)
cooresponding to torque upper limit.
W
Torque upper
limit setting
2005H
Communication setting range
(-10000~10000).
Note:the value(-100.00%~100.00%)
corresponding to torque upper limit.
Write command is valid.
W
Reserved
2006H
W
Motor
temperature
setting
2007H
Communication setting range
(-2000~2000) is corresponding to
(-200.0~200.0).
W
3000H Output speed R
3001H Reference speed R
3002H DC Bus voltage R
3003H Output voltage R
3004H Output current R
3005H Running frequency R
3006H Output power R
3007H Output torque R
3008H Input terminal status R
3009H Output terminal status R
300AH Input of AI1 R
300BH Input of AI2 R
300CH Input of HDI R
300DH Torque compensation R
300EH Pole position R
Status
parameters
300FH ~
3014H
Reserved R
