Size Motor [kg]
Size [kW] 400 V
[A]
065-065-250 200L 37,00 66,36 311.33
080-080-160 132S 5,50 10,49 85.12
080-080-160 132S 7,50 14,12 92.12
080-080-160 160M 11,00 20,41 118.33
080-080-160 160M 15,00 27,25 129.33
080-080-160 160L 18,50 33,38 146.33
080-080-160 180M 22,00 39,52 211.96
080-080-160 200L 30,00 54,73 281.45
080-080-200 160M 11,00 20,41 127.11
080-080-200 160M 15,00 27,25 138.11
080-080-200 160L 18,50 33,38 155.11
080-080-200 180M 22,00 39,52 220.74
080-080-200 200L 30,00 54,73 290.23
080-080-200 200L 37,00 66,36 310.23
100-100-125 132S 5,50 10,49 90.06
100-100-125 132S 7,50 14,12 97.06
100-100-125 160M 11,00 20,41 123.27
100-100-125 160M 15,00 27,25 134.27
100-100-160 160M 11,00 20,41 129.85
100-100-160 160M 15,00 27,25 140.85
100-100-160 160L 18,50 33,38 157.85
100-100-160 180M 22,00 39,52 223.48
100-100-160 200L 30,00 54,73 292.97
100-100-160 200L 37,00 66,36 312.97
125-125-160 160L 18,50 33,38 212.48
125-125-160 180M 22,00 39,52 278.1
125-125-160 200L 30,00 54,73 347.39
125-125-160 200L 37,00 66,36 367.39
125-125-160 225M 45,00 79,45 433.64
125-125-200 180M 22,00 39,52 275.19
125-125-200 200L 30,00 54,73 344.48
125-125-200 200L 37,00 66,36 364.48
125-125-200 225M 45,00 79,45 430.73
n = 1450 rpm
Size Motor [kg]
Size [kW] 400 V
[A]
032-032-160 71M 0,25 0,77 28.68
032-032-160 71M 0,37 1,06 29.88
032-032-160 80M 0,55 1,46 33.24
032-032-160 80M 0,75 1,67 34.64
032-032-160 90S 1,10 2,51 37.57
032-032-200 71M 0,37 1,06 39.01
032-032-200 80M 0,55 1,46 42.37
032-032-200 80M 0,75 1,67 43.77
032-032-200 90S 1,10 2,51 46.7
032-032-200 90L 1,50 3,32 50
032-032-200 100L 2,20 4,67 57.74
040-040-160 71M 0,37 1,06 30.4
040-040-160 80M 0,55 1,46 33.76
040-040-160 80M 0,75 1,67 35.16
040-040-160 90S 1,10 2,51 38.09
040-040-160 90L 1,50 3,32 41.39
040-040-250 80M 0,75 1,67 50.52
040-040-250 90S 1,10 2,51 53.45
040-040-250 90L 1,50 3,32 56.75
040-040-250 100L 2,20 4,67 64.49
040-040-250 100L 3,00 6,18 66.49
040-040-250 112M 4,00 8,23 71.49
040-040-250 132S 5,50 11,32 83.9
Size Motor [kg]
Size [kW] 400 V
[A]
050-050-160 71M 0,37 1,06 34.69
050-050-160 80M 0,55 1,46 38.05
050-050-160 80M 0,75 1,67 39.45
050-050-160 90S 1,10 2,51 42.38
050-050-160 90L 1,50 3,32 45.68
050-050-160 100L 2,20 4,67 53.42
050-050-250 90S 1,10 2,51 56.48
050-050-250 90L 1,50 3,32 59.78
050-050-250 100L 2,20 4,67 67.52
050-050-250 100L 3,00 6,18 69.52
050-050-250 112M 4,00 8,23 74.52
050-050-250 132S 5,50 11,32 86.93
050-050-250 132M 7,50 14,70 100.93
065-065-160 71M 0,37 1,06 36.94
065-065-160 80M 0,55 1,46 40.3
065-065-160 80M 0,75 1,67 41.7
065-065-160 90S 1,10 2,51 44.63
065-065-160 90L 1,50 3,32 47.93
065-065-160 100L 2,20 4,67 55.67
065-065-160 100L 3,00 6,18 57.67
065-065-250 90L 1,50 3,32 63.85
065-065-250 100L 2,20 4,67 71.59
065-065-250 100L 3,00 6,18 73.59
065-065-250 112M 4,00 8,23 78.59
065-065-250 132S 5,50 11,32 91
065-065-250 132M 7,50 14,70 105
065-065-250 160M 11,00 20,80 131.21
080-080-160 80M 0,55 1,46 46.34
080-080-160 80M 0,75 1,67 47.74
080-080-160 90S 1,10 2,51 50.67
080-080-160 90L 1,50 3,32 53.97
080-080-160 100L 2,20 4,67 61.71
080-080-160 100L 3,00 6,18 63.71
080-080-160 112M 4,00 8,23 68.71
080-080-200 90S 1,10 2,51 59.45
080-080-200 90L 1,50 3,32 62.75
080-080-200 100L 2,20 4,67 70.49
080-080-200 100L 3,00 6,18 72.49
080-080-200 112M 4,00 8,23 77.49
080-080-200 132S 5,50 11,32 89.9
080-080-200 132M 7,50 14,70 103.9
080-080-250 100L 2,20 4,67 90.79
080-080-250 100L 3,00 6,18 92.79
080-080-250 112M 4,00 8,23 97.79
080-080-250 132S 5,50 11,32 109.69
080-080-250 132M 7,50 14,70 123.69
080-080-250 160M 11,00 20,80 149.9
080-080-250 160L 15,00 28,11 165.9
100-100-125 80M 0,75 1,67 52.68
100-100-125 90S 1,10 2,51 55.61
100-100-125 90L 1,50 3,32 58.91
100-100-125 100L 2,20 4,67 66.65
100-100-160 90L 1,50 3,32 65.49
100-100-160 100L 2,20 4,67 73.23
100-100-160 100L 3,00 6,18 75.23
100-100-160 112M 4,00 8,23 80.23
100-100-160 132S 5,50 11,32 92.64
100-100-200 100L 2,20 4,67 105.64
100-100-200 100L 3,00 6,18 107.64
100-100-200 112M 4,00 8,23 112.64
100-100-200 132S 5,50 11,32 124.54
100-100-200 132M 7,50 14,70 138.54
100-100-200 160M 11,00 20,80 164.75
Heating / Air-conditioning / Ventilation
In-line Pumps
Etaline / Etaline-R
11
