Size Motor [kg]
Size [kW] 400 V
[A]
100-100-250 100L 3,00 6,18 119.56
100-100-250 112M 4,00 8,23 124.56
100-100-250 132S 5,50 11,32 136.46
100-100-250 132M 7,50 14,70 150.46
100-100-250 160M 11,00 20,80 176.67
100-100-250 160L 15,00 28,11 192.67
100-100-250 180M 18,50 35,28 267.29
125-125-160 100L 2,20 4,67 128.37
125-125-160 100L 3,00 6,18 130.37
125-125-160 112M 4,00 8,23 135.37
125-125-160 132S 5,50 11,32 147.27
125-125-160 132M 7,50 14,70 161.27
125-125-200 100L 3,00 6,18 127.46
125-125-200 112M 4,00 8,23 132.46
125-125-200 132S 5,50 11,32 144.36
125-125-200 132M 7,50 14,70 158.36
125-125-200 160M 11,00 20,80 184.57
125-125-200 160L 15,00 28,11 200.57
125-125-250 132S 5,50 11,32 156.47
125-125-250 132M 7,50 14,70 170.47
125-125-250 160M 11,00 20,80 196.68
125-125-250 160L 15,00 28,11 212.68
125-125-250 180M 18,50 35,28 287.3
125-125-250 180L 22,00 41,27 302.3
150-150-200 132S 5,50 11,32 175.85
150-150-200 132M 7,50 14,70 189.85
150-150-200 160M 11,00 20,80 216.06
150-150-200 160L 15,00 28,11 232.06
150-150-200 180M 18,50 35,28 306.68
150-150-250 132M 7,50 14,70 204.14
150-150-250 160M 11,00 20,80 230.35
150-150-250 160L 15,00 28,11 246.35
150-150-250 180M 18,50 35,28 320.97
150-150-250 180L 22,00 41,27 335.97
150-150-250 200L 30,00 55,19 400.26
150-150-250 225S 37,00 65,47 466.65
200-200-250 160M 11,00 20,80 285.87
200-200-250 160L 15,00 28,11 301.87
200-200-250 180M 18,50 35,28 376.49
200-200-250 180L 22,00 41,27 391.49
200-200-250 200L 30,00 55,19 455.78
200-200-250 225S 37,00 65,47 522.17
200-200-250 225M 45,00 80,19 552.17
200-200-315 180L 22,00 41,27 430.01
200-200-315 200L 30,00 55,19 490.01
200-200-315 225S 37,00 65,47 556.25
200-200-315 225M 45,00 80,19 586.25
200-200-315 250M 55,00 99,89 699.62
Etaline-R
n = 1450 rpm
Pump size Motor Weight
[kg]
Size [kW] 400 V
[A]
150-500/3004 200L 30,00 53,9 874
150-500/3704 225S 37,00 68,0 960
150-500/4504 225M 45,00 81,0 1000
150-500/5504 250M 55,00 96,0 1170
150-500/7504 280S 75,00 130,0 1285
Pump size Motor Weight
[kg]
Size [kW] 400 V
[A]
150-500/9004 228M 90,00 160,0 1385
150-500/11004 315S 110,00 193,0 1551
150-500/13204 315M 132,00 230,0 1706
150-500/16004 315L 160,00 270,0 1846
200-330/1504 160L 15,00 27,8 707
200-330/1854 180M 18,50 34,9 733
200-330/2204 180L 22,00 41,3 750
200-330/3004 200L 30,00 53,9 804
200-330/3704 225S 37,00 68,0 890
200-330/4504 225M 45,00 81,0 930
200-330/5504 250M 55,00 96,0 1110
200-330/7504 280S 75,00 130,0 1225
200-330/9004 228M 90,00 160,0 1325
200-330/11004 315S 110,00 193,0 1491
200-400/3004 200L 30,00 53,9 979
200-400/3704 225S 37,00 68,0 1065
200-400/4504 225M 45,00 81,0 1105
200-400/5504 250M 55,00 96,0 1280
200-400/7504 280S 75,00 130,0 1395
200-400/9004 228M 90,00 160,0 1495
200-400/11004 315S 110,00 193,0 1661
200-400/13204 315M 132,00 230,0 1816
200-400/16004 315L 160,00 270,0 1956
200-400/20004 315L 200,00 340,0 1956
200-500/4504 225M 45,00 81,0 1175
200-500/5504 250M 55,00 96,0 1345
200-500/7504 280S 75,00 130,0 1460
200-500/9004 228M 90,00 160,0 1560
200-500/11004 315S 110,00 193,0 1726
200-500/13204 315M 132,00 230,0 1881
200-500/16004 315L 160,00 270,0 2021
200-500/20004 315L 200,00 340,0 2021
200-500/25004 315L 250,00 434,0 2185
250-250/754 280S 75,00 130,0 620
250-250/1104 315S 110,00 193,0 641
250-250/1504 160L 15,00 27,8 667
250-250/1854 180M 18,50 34,9 693
250-250/2204 180L 22,00 41,3 710
250-250/3004 200L 30,00 53,9 764
250-250/3704 225S 37,00 68,0 850
250-250/4504 225M 45,00 81,0 890
250-260/1104 315S 110,00 193,0 701
250-260/1504 160L 15,00 27,8 727
250-260/1854 180M 18,50 34,9 753
250-260/2204 180L 22,00 41,3 770
250-260/3004 200L 30,00 53,9 824
250-260/3704 225S 37,00 68,0 910
250-260/4504 225M 45,00 81,0 950
250-260/5504 250M 55,00 96,0 1130
250-300/1504 160L 15,00 27,8 882
250-300/1854 180M 18,50 34,9 908
250-300/2204 180L 22,00 41,3 925
250-300/3004 200L 30,00 53,9 979
250-300/3704 225S 37,00 68,0 1065
250-300/4504 225M 45,00 81,0 1105
Heating / Air-conditioning / Ventilation
In-line Pumps
12
Etaline / Etaline-R
