Scarlett SC-4002 [3/6] Antenna

RADIO OPERATION

OPERATION

· Slide the On/Off/Auto/Buzz switch to ON position.

· Select your desired broadcasting band with Band switch.

· Rotate the Tuning control regulator to receive the desired broadcast.

· Adjust the level of sound with Volume control regulator.

ANTENNA

· For FM reception, this set is specially equipped with an FM antenna, which place near the

power line cord.

WAKE TO RADIO

Having selected your station and set the volume as the desired level, proceed as follows:

· Slide the On/Off/Auto/Buzz switch to AUTO position.

· Press the Alarm set button and whilst this button is depressed, press the Hour button and

then the Minute button until the time is reached, at which you wish to wake. The wake up

time is now entered into the timer memory, thus the light indicator AUTO will light up. To

check the wake up time simply press the Alarm set button and the clock will show the preset

time. The preset wake up time will continue to be registered in the timer memory and the

radio will switch on by itself at the same time the next day. To switch the radio off simply

press the Alarm off button.

WAKE TO BUZZER

· Set the controls as for WAKE TO RADIO, but slide the On/Off/Auto/Buzz switch to BUZZ

position. The buzzer can then be switched off by pressing the Alarm off button or it can be

converted to the radio by selecting the On/Off/Auto/Buzz switch to ON position.

SLEEP TO MUSIC

· The radio can be set to play and to switch off automatically for a length of time from 1 minute

to 1 hour 59 minute by following this procedure  with all the controls preset in the WAKE

TO RADIO positions, depress the Sleep button and press the Minute button to count down

to the desired sleep time. To switch off the radio before the end of the registered sleep time

period, simply press the Snooze button.

SNOOZE CONTROL

· The Snooze button allows the user an extra sleep time of about 9 minutes after the radio

alarm is switched on at the preset wake up time. This can be repeated up to 5 times.

MAINTENENCE AND CARE

· Switch off the appliance, unplug from the power supply.

· The outside of the appliance can be cleaned with a slightly damp cloth.

· Avoid leaving the clock radio in direct sunlight or in hot, humid, dusty places. Keep the set

away from heating appliances and appliances that generate noise, such as fluorescent

lamps and motors.

SPECIFICATION

Power supply 220 V, 50 Hz

Net / Gross weight 0.52 kg / 0.58 kg

Gift box dimension (L x W x H) 181 mm x 56 mm x 152 mm
