High Performance Vector Control/Torque Control Inverter User Manual
108
Chapter 6 Parameter Description
PA.17 failure shield and alarm attribute setting 2
Display of operational panel
Unit place
EEPROM abnormality
Tens place
Relay contact abnormality
Hundreds
place
Temperature sampling disconnection
Thousands
place
Encoder disconnection
PA.18 Failure shield and alarm attribute setting 3
Display of operational panel
Unit place
Abnormal +10V power supply output
Tens place
Abnormal analog input
Hundreds
place
Motor over-temperature (PTC)
Thousands
place
Abnormal communication1(operational
panel 485)
PA.19 Failure shield and alarm attribute setting 4
Display of operational panel
Unit place
Abnormal communication2(terminal 485)
Tens place
Abnormal version compatibility
Hundreds
place
Reserved
Thousands
place
Reserved
0: Failure lock disabled.
1: Failure lock enabled: Allowing re-display defaults occurred upon last power failure after power-on
properly run only after resetting failure.
Note:
Whether to output failure indication at the same time is decided by action indication of fault
relay of inverter. Refer to PA.12 instruction.
LU under-voltage cannot be locked upon next time power-up of the inverter as failure.
The function can be used to auto reset from ordinary failures. The inverter will start to run automatically
again after auto reset interval period PA.22. If the failure still exists as the inverter starts again after auto
reset times PA.21, it will alarm then stop. For defaults such as overcurrent or overvoltage occurred
occasionally from beginning or during running, the function can be used if you want the equipment keep
running without manual interfere.
Note: For fault E.PCU, E.rEF, E.AUt, E.FAL, E.oUt, E.ot1, E.ot2, E.Cur, E.GdF, E.LV1, E.CPy, E.dL4,
E.IoF and E.oL3, there has no auto reset function. The inverter will not check fault.
PA.20 Fault locking function selection
0 ~ 1(0)
PA.21 Automatic reset times
0 ~ 20(0)
PA.22 Automatic reset interval
2.0 ~ 20.0 s(2.0s)
