Pressure and temperature limits
Movitec A, B
Movitec A
Pressure and temperature limits
Movitec p T
[bar] [°C]
LHS6 40 120
Movitec B
The pump's pressure and temperature limits are indicated on
the name plate.
Material variants
Overview of pump component materials depending on the design
Part No. Description Movitec
V VC VS LHS 6
10-6 Pump shroud 1.4301 1.4404
101 Pump casing 1.4308 EN-GJL-250 1.4408
108 Stage casing
1.4301
16)
/ 1.4308
17)
1.4404
16)
/ 1.4408
17)
160 Discharge cover
1.4301
16)
/ 1.4308
17)
1.4301
16)
1.4404
16)
/ 1.4408
17)
210 Shaft 1.4057 1.4460
230 Impeller
1.4301
16)
/ 1.4308
17)
1.4404
16)
/ 1.4408
17)
341 Drive lantern
EN-GJL-250
18)
/ EN-GJS-400-15
19)
412 O-ring EPDM-WRc / ACS / ACS EPDM FPM / HNBR
525 Spacer sleeve 1.4301 1.4401
529 Bearing sleeve Tungsten carbide / aluminium oxide
890 Baseplate EN-GJS-400-15 /
EN-GJL-250 /
1.4308
20)
-
EN-GJS-400-15 / EN-GJL-250 / 1.4308
20)
905 Tie bolt 1.4057
920 Nut 1.4301 1.4404
932 Circlip 1.4571
Comparison of materials
EN ASTM
EN-GJL-250 A48 Class 35 B
EN-GJS-400-15 A5369 Grade 60-40-18
1.4057 SS 431
1.4301 SS 304
1.4308 Grade CF8M
1.4404 SS 316L
1.4408 Grade CF8M
1.4460 SS 329
1.4571 SS 316Ti
16)
Movitec 2B, 4B, 6B, 10B, 15B, 25B, 40B, 60B
17)
Movitec 90B
18)
Movitec 2B, 4B, 6B, 10B, 15B, 25B (≤ 4 kW) and Movitec 90B
19)
Movitec 2B, 4B, 6B, 10B, 15B, 25B (≥ 5.5 kW) and Movitec 40B, 60B
20)
Optional for: Movitec 2B, 4B, 6B, 10B, 15B
High-pressure Pumps
High-pressure In-line Pumps
Movitec
13
