KSB Movitec LHV025/04 [18/60] Movitec 2b n 2900 rpm

KSB Movitec LHT025/04 [18/60] High pressure pumps

n = 2900 rpm

Movitec; 2B; n = 2900 rpm

K95000200/2

0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5

Q [m³/h]

0 5 10 15

Q [US.gpm]

0 2 4 6 8 10 12

Q [IM.gpm]

100

150

200

250

H [m]

200

400

600

800

H [ft]

0.0 0.2 0.4 0.6 0.8 1.0

Q [l/s]

NPSH

[m]

NPSH

[ft]

Eta [%]

0.05

0.02

0.08

P [kW]

0.1

0.04

P [hp]

0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5

Q [m³/h]

2/30 2,2kW

2/28 2,2kW

2/26 2,2kW

2/24 2,2kW

2/22 2,2kW

2/20 1,5kW

2/18 1,5kW

2/16 1,5kW

2/14 1,1kW

2/12 1,1kW

2/11 1,1kW

2/10 0,75kW

2/9 0,75kW

2/8 0,55kW

2/7 0,55kW

2/6 0,55kW

2/5 0,37kW

2/4 0,37kW

2/3 0,37kW

2/2 0,37kW

St=1

St = Number of stages

The power input P is indicated per stage

High-pressure Pumps

High-pressure In-line Pumps

Movitec
