Best Chef GH 61 FS IX [7/32] Installation instructions
![Best Chef GH 62 LCT IX [7/32] Installation instructions](/views2/1593502/page7/bg7.png)
Important!
-
These instructions are intended for qualified technicians.
-
The appliance must be installed correctly, in compliance with current laws.
-
Before carrying out any operation on the appliance, it must be disconnected from the electric supply.
Fitting the appliance in the worktop
The cooktop may be fitted into any worktop, as long as it is heat resistant (minimum temperature of 90°C)
The dimensions of the hole to be made in the worktop and the minimum distances between rear
and side walls and those above the appliance are shown in figures 5 and 6
Fig.5
GH61B / GH61BS
GH62F / GH61F
GH62LC
GH62LC
290
585
585
595
290
290
490
480
480
480
490
490
270
560
560
560
270
270
510
500
500
510
510
510
EDABC
fig.6
560 480 510 685 35
35
35
35
40
INSTALLATION INSTRUCTIONS
WH31 / GH31
BH31
50
270 490 510 290 150
FH31
EH31B / VH31HL
45
5
