RIP configuration mode
OSPF configuration mode
PIM configuration mode
GN.Link configuration mode
The function and details of each command mode are as following:
Table 1-1 Command Line Configuration Mode
Command line
mode
Function
Prompt
character
Command for
entering
Command for
exiting
User mode
See switch
operation
information
QTECH>
Connect with
switch after
inputting user
name and
password
exit disconnect
with switch
Privileged mode
See switch
operation
information
and manage
system
QTECH#
Input enable in
user mode
exit return to user
mode
quit disconnect
with switch
Global
configuration
mode
Configure
global
parameter
QTECH(con
fig)#
Input configure
terminal in
privileged mode
exit, end return to
privileged mode
quit disconnect
with switch
Interface
configuration
mode
Configure
interface
parameter
QTECH(con
fig-if-
ethernet-
0/1)#
Input «interface
Ethernet 0/1» in
global
configuration
mode, interface
configuration can
enter other
interface mode
and VLAN
configuration mode
without inputting
«exit» .
end return to
privileged mode
exit return to global
configuration mode
quit disconnect
with switch
VLAN
configuration
mode
Configure
VLAN
parameter
QTECH(con
fig-if-vlan)#
Input «vlan 2» in
global
configuration
mode, VLAN
configuration mode
can enter other
VLAN mode and
interface
configuration mode
without inputting
«exit» .
AAA
configuration
mode
Create domain
QTECH(con
fig-aaa)#
Input «aaa» in
global
configuration mode
