QTECH Software Configuration Manual
16-213
Configure it in interface configuration mode :
dot1x port-control { auto | forceauthorized | forceunauthorized }
For example :
! Ethernet 0/0/5 is RADIUS server port. Configure port-control mode of ethernet 0/0/5 to be forceauthorized
in interface configuration mode
QTECH(config-if-ethernet-0/0/5)#dot1x port-control forceauthorized
! Display 802.1X configuration of ethernet 0/0/5
QTECH(config)#show dot1x interface ethernet 0/0/5
port ctrlmode Reauth ReauthPeriod(s) MaxHosts
e0/0/5 forceauthorized disabled 3600 160
Total [26] item(s), printed [1] item(s).
(6) Use dot1x max-user command to configure the maximum number of supplicant systems an ethernet port
can accommodate. Use no dot1x max-user command to configure the maximum number to be 1.
Configure it by using following command :
dot1x max-user user-num
For example :
! Configure the max-user of ethernet 0/0/5 is 10 in interface configuration mode
QTECH(config-if-ethernet-0/0/5)#dot1x max-user 10
(7) Use dot1x user cut command to remove specified online user.
Remove specified online user by specified username and MAC address.
For example :
! Remove user with username of aaa@QTECH.com
QTECH(config)#dot1x user cut username aaa@QTECH.com
