QTECH Software Configuration Manual
22-243
reply from 001f : ce10 : 14f1
5 packets transmitted, 5 packets received, 0.0% packet loss
22.4.9 cfm traceroute
cfm traceroute command is used for link tracert and checking network connection. Configure it in global
configuration mode :
cfm traceroute [-f first_ttl | -h maximum_hops | -w time_out ] target-mac level level-id vlan vlan-id
Parameter :
first_ttl : first ttl of sending packet which is in the range of 1 to 255 and default value is 255;
maximum_hops : max ttl of sending packet which is in the range of 1 to 255 and default value is 10;
time_out : the response timeout after sending packet which is in the range of 10 to 60 with the unit of second
and default value is 5 seconds;
target_mac : destination mac address
level-id : the integrity from 0-7
vlan-id : VLAN to be tracerted
For example :
! cfm traceroute 00 : 1f : ce : 10 : 14 : f1 level 4 vlan 110
QTECH#cfm traceroute 00 : 1f : ce : 10 : 14 : f1 level 4 vlan 110
22.4.10 Display cfm domain
Configure it in any configuration mode :
It will display as following :
· cfm domain name
· cfm domain level
show cfm domain
For example :
! Display cfm domain
QTECH(config)#show cfm domain
22.4.11 Display cfm maintenance-points local
Configure it in any configuration mode :
It will display as following :
§ cfm maintenance-points mpid
§ cfm maintenance-points type
§ cfm maintenance-points vlan
§ cfm maintenance-points level
§ cfm maintenance-points interface
§ Enable/disable cfm maintenance-points
§ cfm maintenance-points mac address
show cfm maintenance-points local
