14. QOS Configuration Command 232

www.qtech.ru

Optiway(config-if-fastEthernet-1)#line-rate 12

14.1.3. Mirrored-to

Use mirrored-to command to enable ACL identified flow. Use no mirrored-to command to

cancel flow mirror.

mirrored-to { [ ip-group access-list-number | access-list-name [ subitem

subitem ] ] [ link-group access-list-number | access-list-name [ subitem

subitem ] ] } } [ interface interface-num ]

no mirrored-to {[ ip-group access-list-number | access-list-name [ subitem

subitem ] ] [ link-group access-list-number | access-list-name [ subitem

subitem ] ] } }

ip-group { access-list-number | access-list-name } [ subitem subitem ] :means

standard or extended accessing control list. access-list-number:sequence

number of accessing list which is in the range of 1～199；access-list-name:the

name of accessing list which is the character string and in the form of

initial capitalized characters ([a-z, A-Z]), excluding space and quotation

mark；subitem subitem:optional parameter, specifies the subitem in accessing

list which is in the range of 2～127. If it is not specified, all subitems

will be clear.

link-group { access-list-number | access-list-name } [ subitem

subitem ] :means layer 2 accessing control list. access-list-number:accessing

list serial number which is in the range of 222～299；access-list-name:name of

accessing list. Character string is in the form of initial capitalized

characters ([a-z, A-Z]), excluding space and quotation mark；subitem

subitem:optional parameter, specifies the subitem in accessing list which is

in the range of 2～127. If it is not specified, all subitems will be clear.

interface { interface-num }:specified data flow destination mirror interface.

interface-num is the interface number.

【Command configuration mode】

Global configuration mode

【Usage】

Use this command to flow mirror the data packet which matched specified accessing list

regulations (it is only be effective for permit rules of accessing list). The interface of destination

mirror cannot be Trunk or convergent interface. Switch can only support one destination

mirror port. Mirror destination port must be specified when using this command to configure

flow mirror for the first time.

【Example】

！Mirror flow the data packet which matches the permit rules of accessing list 1 to ethernet 1

Optiway(config)#mirrored-to ip-group 1 interface ethernet 2/1
