Dimensions in millimeters.
Inch equivalents shown in [ ].
Engine Dimensions with Heavy-Duty Air Cleaner
93.30
[3.673]
EXHAUST
PORT #1
73.30
[2.886]
EXHAUST
PORT #2
OIL DRAIN PLUG
3/8 NPT (INCH)
40.80
[1.606]
ENGINE MOUNTING
SURFACE
14.20
[.559]
317.77
[12.511]
377.59
[14.866]
155.30
[6.114]
SPARK PLUG
424.75
[16.722]
89.94
[3.541]
134.97
[5.314]
15.76
[.621]
495.31
[19.501]
45.59
[1.795]
126.31
[4.973]
OIL FILL &
DIPSTICK
MOUNTING
HOLE “A”
15.75
[.620]
OIL FILTER
REMOVAL
301.77
[11.881]
130.03
[5.119]
AIR FILTER COVER
ASSEMBLY REMOVAL
SAFTY AIR FILTER
ELEMENT REMOVAL
PRIMARY AIR FILTER
ELEMENT REMOVAL
AIR FILTER RAIN
CAP REMOVAL
SPARK PLUG
FUEL
FILTER
275.56
[10.849]
15.80
[.622]
SPARK PLUG
417.59
[16.441]
529.91
[20.863]
CRANKSHAFT
89.41
[3.520]
241.66
[9.514]
77.68
[3.058]
334.19
[13.157]
50.00
[1.969]
EXHAUST
PORT #1
2X 89.41
[3.520]
2X 72.85
[2.868]
M8 X 1.25
4 STUDS
SOLENOID
SHIFT STARTER
MOUNTING HOLE “A”
4X Ø 9.20 [.362] THRU
Ø 254.00 [10.00] B.C.
104.02
[4.095]
50.00
[1.969]
EXHAUST
PORT #2
30˚
30˚
405.97
[15.983]
247.90
[9.760]
REGULATOR
RECTIFIER
135.30
[5.327]
SPARK
PLUG
52.76
[2.077]
OIL FILTER
14.44
[.569]
96.37
[3.794]
MOUNTING
HOLE “A”
26.41
[1.040]
405.97
[15.983]
OIL DRAIN PLUG
3/8 NPT (INCH)
85.50
[3.366]
KEYWAY
7/16-20 UNF 2B (INCH)
38.1 [1.500]
1/4 IN. SQ KEYWAY
Ø 28.56
[1.125]
ENGINE MOUNTING
SURFACE
449.63
[17.702]
PULSE FUEL
PUMP
OIL COOLER
Specifi cations
724 690 07 Rev. J KohlerEngines.com
