Kohler Command PRO CV752 [11/68] Speciﬁ cations

Speciﬁ cations

1124 690 37 Rev. D KohlerEngines.com

CLEARANCE SPECIFICATIONS

CV682 CV732 CV742 CV752

Valves and Valve Lifters

Hydraulic Valve Lifter to Crankcase Running Clearance 0.0241/0.0501 mm (0.0009/0.0020 in.)

Intake Valve Stem-to-Valve Guide Running Clearance 0.038/0.076 mm (0.0015/0.0030 in.)

Exhaust Valve Stem-to-Valve Guide Running Clearance 0.050/0.088 mm (0.0020/0.0035 in.)

Intake Valve Guide I.D.

New

Max. Wear Limit

7.038/7.058 mm (0.2771/0.2779 in.)

7.134 mm (0.2809 in.)

Exhaust Valve Guide I.D.

New

Max. Wear Limit

7.038/7.058 mm (0.2771/0.2779 in.)

7.159 mm (0.2819 in.)

Valve Guide Reamer Size

Standard

0.25 mm O.S

7.048 mm (0.2775 in.)

7.298 mm (0.2873 in.)

Intake Valve Minimum Lift 8.07 mm (0.3177 in.)

Exhaust Valve Minimum Lift 8.07 mm (0.3177 in.)

Nominal Valve Seat Angle 45°

Values are in Metric units. Values in parentheses are English equivalents.
