Tools and Aids
1719 690 01 Rev. D KohlerEngines.com
TOOLS
Description Source/Part No.
Hose Removal Tool, Dual Size/End (also available in EFI Service Kit)
Used to properly remove fuel hose from engine components.
Kohler 25 455 20-S
Hydraulic Valve Lifter Tool
For removing and installing hydraulic lifters.
Kohler 25 761 38-S
Ignition System Tester
For testing output on all systems, including CD.
Kohler 25 455 01-S
Inductive Tachometer (Digital)
For checking operating speed (RPM) of an engine.
Design Technology Inc.
DTI-110
Off set Wrench (K and M Series)
For removing and reinstalling cylinder barrel retaining nuts.
Kohler 52 455 04-S
Oil Pressure Test Kit
For testing/verifying oil pressure on pressure lubricated engines.
Kohler 25 761 06-S
Rectifi er-Regulator Tester (120 volt current)
Rectifi er-Regulator Tester (240 volt current)
For testing rectifi er-regulators.
Components of 25 761 20-S and 25 761 41-S
CS-PRO Regulator Test Harness
Special Regulator Test Harness with Diode
Kohler 25 761 20-S
Kohler 25 761 41-S
Design Technology Inc.
DTI-031R
DTI-033R
Spark Advance Module (SAM) Tester
For testing SAM (ASAM and DSAM) on engines with SMART-SPARK
™
.
Kohler 25 761 40-S
Starter Servicing Kit (All Starters)
For removing and reinstalling drive retaining rings and brushes.
Individual component available:
Starter Brush Holding Tool (Solenoid Shift)
SE Tools KLR-82411
SE Tools KLR-82416
Triad/OHC Timing Tool Set
For holding cam gears and crankshaft in timed position while installing timing belt.
Kohler 28 761 01-S
Valve Guide Reamer (K and M Series)
For properly sizing valve guides after installation.
Design Technology Inc.
DTI-K828
Valve Guide Reamer O.S. (Command Series)
For reaming worn valve guides to accept replacement oversize valves. Can be used
in low-speed drill press or with handle below for hand reaming.
Kohler 25 455 12-S
Reamer Handle
For hand reaming using Kohler 25 455 12-S reamer.
Design Technology Inc.
DTI-K830
AIDS
Description Source/Part No.
Camshaft Lubricant (Valspar ZZ613) Kohler 25 357 14-S
Dielectric Grease (GE/Novaguard G661) Kohler 25 357 11-S
Dielectric Grease Loctite
®
51360
Kohler Electric Starter Drive Lubricant (Inertia Drive) Kohler 52 357 01-S
Kohler Electric Starter Drive Lubricant (Solenoid Shift) Kohler 52 357 02-S
RTV Silicone Sealant
Loctite
®
5900
®
Heavy Body in 4 oz. aerosol dispenser.
Only oxime-based, oil resistant RTV sealants, such as those listed, are approved
for use. Permatex
®
the Right Stuff
®
1 Minute Gasket™ or Loctite
®
Nos. 5900
®
or
5910
®
are recommended for best sealing characteristics.
Kohler 25 597 07-S
Loctite
®
5910
®
Loctite
®
Ultra Black 598™
Loctite
®
Ultra Blue 587™
Loctite
®
Ultra Copper 5920™
Permatex
®
the Right Stuff
®
1
Minute Gasket™
Spline Drive Lubricant Kohler 25 357 12-S
