Specifi cations
719 690 01 Rev. D
KohlerEngines.com
Engine Dimensions-Engine Mounting Surface (PTO End)
A 2 X 45° B 72.8 mm (2.87 in.) C 121.5 mm (4.78 in.) D
2 X 20.8 mm
(0.82 in.)
E
2 X 135.2 mm
(5.32 in.)
F 2 X 20° G
298.0 mm
(11.73 in.)
H
193.8 mm
(7.63 in.)
I 89.8 mm (3.54 in.) J
Oil Filter Removal
18.0 mm (0.71 in.)
K Mounting Hole "A" L 138.1 mm (5.44 in.)
M Direction of Rotation N 45° O 35° P
Starter Stud
259.7 mm (10.22 in.)
Q
4 X 3/8-16
UNC-2B in.
25 mm (0.98 in.)
Deep on a Ø
254 mm (10.0 in.)
B.C.
R
Starter Stud
104.5 mm (4.11 in.)
S
M8 X 1.25 mm
Stud/Nut
T
4 X M8 X 1.25 mm
Studs
U
2 X 68.0 mm
(2.68 in.)
V 422.6 mm (16.64 in.)
U
B B
A
C
E
F
G
H
I
J
LII
P
N N
M
O O
D
T
S
R
H
G
Q
K
V
