Specifi cations
524 690 31 Rev. D KohlerEngines.com
Dimensions in millimeters.
Inch equivalents shown in [ ].
412.98
[16.259]
296.38
[11.668]
269.48
[10.609]
96.02
[3.780]
135.00
[5.315]
AIR FILTER RAIN CAP
REMOVAL
130.00
[5.118]
AIR FILTER
COVER ASSEMBLY
REMOVAL
73.06
[2.877]
SPARK PLUG REMOVAL
52.36 [2.061]
SPARK PLUG
BOOT REMOVAL
22.84 [0.899]
SPARK PLUG BOOT
246.07
[9.688]
SPARK
PLUG
BOOT
REMOVAL
253.53
[9.982]
SPARK
PLUG
REMOVAL
417.98 [16.456]
SAFETY AIR FILTER
ELEMENT REMOVAL
530.30 [20.878]
PRIMARY AIR FILTER
ELEMENT REMOVAL
OIL FILL & DIPSTICK
MOUNTING
HOLE “A”
ENGINE
495.66
[19.514]
ENGINE
152.99
[6.023]
45.35
[1.786]
137.09
[5.397]
15.70
[0.618]
OIL FILTER
REMOVAL
81.86
[3.223]
73.23 [2.883]
SPARK PLUG REMOVAL
52.45
[2.065]
SPARK PLUG
BOOT REMOVAL
27.43
[1.080]
SPARK PLUG
BOOT
246.28
[9.696]
SPARK
PLUG
BOOT
REMOVAL
253.53
[9.982]
SPARK
PLUG
REMOVAL
20˚
20˚
FLYWHEEL SIDE
154.08
[6.066]
92.08
[3.625]
EXHAUST
PORT #1
72.08
[2.838]
EXHAUST
PORT #2
STARTER SIDE
367.38
[14.464]
13.38
[0.527]
40.80
[1.606]
ENGINE MOUNTING
SURFACE
OIL DRAIN PLUG
3/8 N.P.T INCH
405.85
[15.978]
247.85
[9.758]
445.32
[17.532]
OIL COOLER
REGULATOR RECTIFIER
REGULATOR ASSEMBLY
143.17
[5.636]
134.45
[5.293]
50.78
[1.999]
13.72
[0.540]
11.81
[0.465]
26.80
[1.055]
86.30
[3.398]
24.895 ± 0.10 [0.980 ± 0.0039]
Ø 28.56 ± 0.01 [1.125 ± 0.005]
OXYGEN
SENSOR
SPARK
PLUG
ENGINE MOUNTING
SURFACE
OIL FILTER SIDE
7/16-20 UNF 2B IN
97.2
[3.827]
38.1 +0.00 -3.81
[1.500 +0.00 -0.150]
ENGINE MOUNTING SURFACE
PTO END
334.4
[13.164]
94.26
[3.711]
15˚
MOUNTING
HOLE “D”
152.25
[5.994]
104.03
[4.096]
89.80
[3.536]
MOUNTING
HOLE “A”
MOUNTING
HOLE “B”
MOUNTING
HOLE “C”
242.22
[9.536]
48.39
[1.905]
50
[1.969]
EXHAUST
PORT #2
SOLENOID
SHIFT STARTER
45˚ ± 0.135˚
45˚ ± 0.135˚
35˚ ± 0.135˚
35˚ ± 0.135˚
72.84 ± 0.30
[2.868 ± 0.118]
15˚
4X Ø 8.64.7.54 [0.340/0.297 THRU
Ø 254.00 ± 0.3 [10.000] B.C.
2X 89.80
[3.536]
50
[1.969]
EXHAUST
PORT #2
Engine Dimensions
