15
Repair
•
Never open or repair the instrument, otherwise
perfect functioning is no longer guaranteed. If
these instructions are not heeded, the warranty
becomes null and void.
•
In the event of repairs, please contact customer
service or an authorised dealer.
3. Instrument Description
Nutritional analysis scale
1 On/off button
2 M+ To store measurement
3 MR To display sum values
4 MC To clear memory
5 Switch to change the weight units (g/oz) unit
6 Tare button tara
7 Display
7.1 Kilocalories display
7.2 Kilojoules display
7.3 Displaying the carbohydrate content
7.4 Displaying the cholesterol content
7.5 Fat content display
7.6 Displaying the code
7.7 Weight display
7.8 Displaying the number of memory spaces
7.9 Protein content display
7.10 Bread units display
8
Digital buttons 0 – 9 for entering the foodstuffs code
9 Battery compartment (back)
4. Start-up
Changing the weight unit
The scales can display values in the weight units
g (grams) or oz (ounces). The default setting is in
grams. You can adjust the unit using the unit button.
Positioning scales
Place the scales on a firm, even surface. A firm base
is essential to correct measurement.
5. Operation
5.1 Weighing
Switching on scales
The display shows the weight of the item to be
weighed. Press the
button.
Weighing additional items (tare)
To weigh additional quantities you can reset the
scales to 0 g.
➔
To do this, press tara.
Entering the foodstuffs code
➔
From the food list (page 17 onwards), find the
3-digit code for the material you want to weigh
and enter this number using the digit buttons.
If you have entered the wrong number, fill in the code
with any numbers up to three digits. Then reenter the
code again.
The display now shows all nutritional and energy val-
ues.
Please note that, due to natural fluctuations in the
nutritional and energy values of foodstuffs only
approximate data is possible.
Switching off scales
The scales switch off automatically 180 seconds
after the last weighing change.
Press the
button to switch off manually.
5.2 Saving weighed items
You can save the weight, nutritional and energy val-
ues of the foodstuff currently being measured. The
scales automatically add up the values of each meas-
urement stored. You can view the total weight, total
nutritional values and total energy values at any time.
The saved data is retained even if the scales are
switched on and off or if the battery is changed.
Saving the first measurement
You have previously done a measurement and
entered the foodstuffs code.
➔
Press the memory button M+.
The display shows the summation symbol ΣM, the
memory space (e.g. 01) and the total weight.
Saving other measurements
Substitute the item to be weighed and repeat step 1.
Displaying added measured values
7.9
7.10
7.8
7.5
7.6
7.7
7.4
7.1 7.2 7.3
9
1
2
3
4
8
7
6
5
