Moser GenioPlus [12/94] English

ENGLISH

Operation

· Switch on the appliance using the on/off switch (Fig. 4

ⓐ

) and, after use, switch it off again

(Fig. 4

ⓑ

· When pressing the slide switch, the control light (G) will light up briefly, indicating the readi-

ness of the appliance.

Cutting-length adjustment

The cutting length can be adjusted to between 0.7mm and 3mm (5 possible positions) using the

cutting-length adjustment integrated into the blade set (Fig. 5). To do this, set the adjustment

lever to the desired position and let it snap into place.

Cutting with attachment combs

The appliance can also be operated with attachment combs. In order to achieve the indicated

cutting length, the cutting length adjustment lever should to be set to position 1 (Fig. 5). The

following attachment combs are included as standard: 3 mm, 6 mm, 9 mm and 12 mm cutting

lengths. Attachment combs with 18 mm and 25 mm cutting length are available as optional

accessories.

Attaching/removing the attachment comb

· Slide the attachment comb on to the blade set in the direction of the arrow until it reaches the

limit stop (Fig. 6

ⓐ

· The attachment comb can be removed by pushing it in the direction of the arrow (Fig. 6

ⓑ

Cleaning and Care

· Do not immerse the appliance in water!

· After each use, remove the attachment comb and use the cleaning brush to remove cut hairs

from the housing opening and from the blade set. To do this, remove the blade set

(Fig. 7

ⓐ

) and press the cleaning lever (Fig. 8). This allows the cut hairs that accumulate

between the bottom blade and the top blade to be easily removed using the cleaning brush

(

EASY CLEANING).

· The charging contacts on the appliance and charging stand should always be kept clean.

· Only wipe the appliance with a soft cloth, which may be dampened slightly. Do not use sol-

vents or abrasives!

· The blade set can be cleaned with hygienic spray, order no. 4005-7051.

· The 4in1 Blade Ice spray (order no. 2999-7900) delivers instant cooling, oiling and cleaning

of the blade set, while also providing corrosion inhibiting action.

· For a long-lasting, good cutting performance, it is important to oil the blade set frequently

(Fig. 9). Use only blade set oil for this purpose, order no. 1854-7935 (200 ml).

· Bladesetoil,hygienicsprayand“BladeIce”sprayareavailablefromyourdealerorour

Service Center.

· If the cutting performance deteriorates after long use despite regular cleaning and oiling, the

blade set should be replaced.
