Lowara CEA 370/3/P 104480270 [36/48] Table of water requirements in civil users
![Lowara CEA4 70/3/A [36/48] Table of water requirements in civil users](/views2/1612144/page36/bg24.png)
36
NUMBER OF
APARTMENTS 1212
1 32406079
2 455685111
3 55 68 105 136
4 63 79 121 157
5 71 88 135 176
6 78 97 148 193
7 84 105 160 208
8 90 112 171 223
9 95 119 181 236
10 100 125 191 249
11 105 131 200 261
12 110 137 209 273
13 114 143 218 284
14 119 148 226 295
15 123 153 234 305
16 127 158 242 315
17 131 163 249 325
18 134 168 256 334
19 138 172 263 343
20 142 177 270 352
21 145 181 277 361
22 149 185 283 369
23 152 190 290 378
24 155 194 296 386
25 158 198 302 394
26 162 202 308 401
27 165 205 314 409
28 168 209 320 417
29 171 213 325 424
30 174 217 331 431
35 187 234 357 466
40 200 250 382 498
45 213 265 405 528
50 224 280 427 557
55 235 293 448 584
60 245 306 468 610
65 255 319 487 635
70 265 331 506 659
75 274 342 523 682
80 283 354 540 704
85 292 364 557 726
90 301 375 573 747
95 309 385 589 767
100 317 395 604 787
120 347 433 662 863
140 375 468 715 932
160 401 500 764 996
180 425 530 811 1056
200 448 559 854 1114
For seaside resorts, a flow rate increased by at least 20% must be considered.
G-at-fi_a_th
FLOW RATE (l/min)
WITH FLUSH TANK WC WITH CONTROLLED FLUSHING SYSTEM WC
TABLE OF WATER REQUIREMENTS IN CIVIL USERS
TECHNICAL APPENDIXTECHNICAL APPENDIX
TECHNICAL APPENDIXTECHNICAL APPENDIX
TECHNICAL APPENDIX
