FCE-FCS SERIES
HYDRAULIC PERFORMANCE TABLE AT 50Hz, 2 POLES
PUMP
TYPE
l/min 0 100 200 350 375 400 600 700 800 850 1000 1200 1300 1500 1600 1750 1950 2500 3000
m
3
/h 0
6 12 21 22,5 24 36 42 48 51 60 72 78 90 96 105 117 150 180
kW HP
40-125/07 0,75 1 17,1 15,1 11,8 3,6
40-125/11 1,1 1,5 22,6 20,2 16,7 8,8 7,0
40-160/15 1,5 2 27,3 24,7 20,9 13,1 11,3 9,3
40-160/22 2,2 3 35,3 32,6 28,8 21,1 19,5 17,7
40-200/* * * 42,5 38,9 34,0
40-200/40 4 5,5 51,0 46,9 41,7 30,6
40-200/55 5,5 7,5 62,0 57,6 51,3 39,6 37,1
40-250/75 7,5 10 75,4 71,1 65,0 52,9 50,3
40-250/110 11 15 85,2 80,8 74,8 62,3 59,6 56,6
50-125/11/A 1,1 1,5 15,3 13,5 11,1 10,6 10,1 5,4
50-125/15/A 1,5 2 19,1 17,5 14,9 14,4 13,8 8,6 5,5
50-160/22 2,2 3 26,1 23,9 21,1 20,5 20,0 14,7 11,6
50-160/30 3 4 32,8 30,6 27,2 26,5 25,9 19,9 16,6 13,1
50-160/40 4 5,5 38,1 36,1 32,9 32,3 31,6 25,1 21,3 17,3 15,3
50-200/55 5,5 7,5 47,0 43,5 39,6 38,8 38,0 30,3
50-200/75 7,5 10 56,0 52,0 48,2 47,5 46,7 39,4 34,9
50-250/** ** ** 63,2 59,4 55,3 54,5 53,8 46,7 42,6 38,0
50-250/110 11 15 69,4 65,3 61,3 60,6 59,8 53,2 49,4 45,0 42,5
50-250/150 15 20 83,0 79,2 75,1 74,4 73,6 66,1 61,6 56,6 53,9
65-125/22 2,2 3 18,8 16,4 14,3 13,0 11,4 10,6 7,9
65-125/30 3 4 22,9 20,3 18,1 16,7 15,2 14,3 11,6
65-125/40 4 5,5 26,6 24,4 22,4 21,1 19,7 18,9 16,3 12,1
65-160/55 5,5 7,5 35,1 32,5 30,1 28,7 27,1 26,3 23,5 19,1
65-160/75 7,5 10 42,4 40,0 37,4 35,8 34,0 33,1 29,9 25,2 22,5
65-200/** ** ** 53,0 47,6 44,1 42,2 40,1 39,0 35,2 28,4 24,0
65-200/110 11 15 61,0 55,2 51,3 49,3 47,1 45,9 42,1 35,8 31,8
65-250/150 15 20 70,0 66,3 63,0 61,1 58,9 57,8 54,2 48,9 46,1 40,0
65-250/185 18,5 25 80,0 75,2 71,8 69,9 67,7 66,6 63,0 57,6 54,6 47,9
65-250/220 22 30 89,0 84,3 80,7 78,7 76,5 75,3 71,6 66,0 63,0 56,3 52,6
80-125/30 3 4 15,5 14,5 14,1 13,6 13,3 12,3 10,7 9,9
80-125/40 4 5,5 19,0 18,0 17,6 17,0 16,8 15,8 14,2 13,3 11,5
80-125/55 5,5 7,5 23,0 21,5 21,0 20,5 20,2 19,3 18,0 17,2 15,5 14,5
80-160/75 7,5 10 28,0 26,5 26,1 25,6 25,4 24,7 23,6 23,0 21,6 20,8 19,5
80-200/110 11 15 41,0 37,0 36,2 35,2 34,7 33,2 30,7 29,3 26,2 24,5 21,5
80-200/150 15 20 49,4 46,3 45,6 44,8 44,3 43,0 41,0 39,9 37,5 36,2 33,9 30,5
80-200/185 18,5 25 56,9 53,4 52,6 51,7 51,2 49,8 47,9 46,9 44,7 43,5 41,4 38,1
80-200/220 22 30 65,2 61,3 60,4 59,5 59,0 57,6 55,5 54,5 52,2 51,0 49,1 46,0
100-160/110 11 15 29,0 28,0 27,3 26,9 25,9 25,4 24,6 23,4 19,5
100-200/185 18,5 25 45,0 39,5 38,8 37,5 36,8 35,9 34,5 30,4 25,0
100-200/220 22 30 53,0 48,0 47,3 46,0 45,3 44,3 42,9 38,7 33,6
* FCE40-200/40A : 4 (kW) - 5.5 (HP) FCS40-200/30 : 3 (kW) - 4 (HP)
fce-fcs-2p50-en_d_th
** FCE50-250/92 : 9.2 (kW) - 12.5 (HP) FCS50-250/110A : 11 (kW) - 15 (HP)
FCE65-200/92 : 9.2 (kW) - 12.5 (HP) FCS65-200/110A : 11 (kW) - 15 (HP)
Performances according to ISO 9906 - Annex A
RATED
POWER
Q = DELIVERY
H = TOTAL HEAD METRES COLUMN OF WATER
