LIST OF FC SERIES MODELS 50 HzLIST OF FC SERIES MODELS 50 Hz
LIST OF FC SERIES MODELS 50 HzLIST OF FC SERIES MODELS 50 Hz
LIST OF FC SERIES MODELS 50 Hz
FC - FCT (2 POLES) FC.4 - FCTFC - FCT (2 POLES) FC.4 - FCT
FC - FCT (2 POLES) FC.4 - FCTFC - FCT (2 POLES) FC.4 - FCT
FC - FCT (2 POLES) FC.4 - FCT
.4 (4 POLES).4 (4 POLES)
.4 (4 POLES).4 (4 POLES)
.4 (4 POLES)
ELENCO MODELLI SERIE FC - FCT
50 Hz 2 POLI
SIZE
kW
FCEM FCE FCS
FCTEM FCTE FCTS
40-125/07 0,75
•••
40-125/11 1,1
•••
40-160/15 1,5
•••
40-160/22 2,2
•••
40-200/30 3
--•
40-200/40A 4
-•-
40-200/40 4
-••
40-200/55 5,5
-••
40-250/75 7,5
-••
40-250/110 11
-••
50-125/11 1,1
•••
50-125/15 1,5
•••
50-160/22 2,2
•••
50-160/30 3
-••
50-160/40 4
-••
50-200/55 5,5
-••
50-200/75 7,5
-••
50-250/92 9,2
-•-
50-250/110A 11
--•
50-250/110 11
-••
50-250/150 15
-••
65-125/22 2,2
•••
65-125/30 3
-••
65-125/40 4
-••
65-160/55 5,5
-••
65-160/75 7,5
-••
65-200/92 9,2
-•-
65-200/110A 11
--•
65-200/110 11
-••
65-250/150 15
-••
65-250/185 18,5
-••
65-250/220 22
-••
80-125/30 3
-••
80-125/40 4
-••
80-125/55 5,5
-••
80-160/75 7,5
-••
80-200/110 11
-••
80-200/150 15
-••
80-200/185 18,5
-••
80-200/220 22
-••
100-160/110 11
-••
100-200/185 18,5
-••
100-200/220 22
-••
•
= Available
fc_fce-fcs_2p50-en_b_tem
VERSION
ELENCO MODELLI SERIE FC4 - FCT4
50 Hz 4 POLI
SIZE
kW
FCE4
FCTE4 FCS4 FCTS4
40-125/02A 0,25
•- -
40-125/02 0,25
•- -
40-160/02 0,25
•- -
40-160/03 0,37
•- -
40-200/05 0,55
•••
40-200/07 0,75
•••
40-250/11 1,1
•••
40-250/15 1,5
•••
50-125/02 0,25
•- -
50-125/03 0,37
•- -
50-160/05 0,55
•- -
50-200/07 0,75
•••
50-200/11 1,1
•••
50-250/15 1,5
•••
50-250/22 2,2
•••
65-125/03 0,37
•- -
65-125/05 0,55
•- -
65-160/07 0,75
•••
65-160/11 1,1
•••
65-200/15 1,5
•••
65-250/22 2,2
•••
65-250/30 3
•••
80-125/07 0,75
•••
80-125/11 1,1
•••
80-200/15 1,5
•••
80-200/22 2,2
•••
80-200/30 3
•••
80-250/40 4
•••
80-250/55 5,5
•••
100-160/15 1,5
•••
100-200/22 2,2
•••
100-200/30 3
•••
100-250/40 4
•••
100-250/55 5,5
•••
100-250/75 7,5
•••
125-160/30 3
-••
125-200/40 4
-••
125-200/55 5,5
-••
125-250/75 7,5
-••
125-250/110 11
-••
125-315/150 15
-•-
125-315/185 18,5
-•-
125-315/220 22
-•-
150-200/55 5,5
-••
150-200/75 7,5
-••
150-250/110 11
-••
150-250/150 15
-••
150-250/185 18,5
-••
•= Available
fc_fce4-fcs4_4p50-en_b_tem
VERSION
