101
FCE4 SERIESFCE4 SERIES
FCE4 SERIESFCE4 SERIES
FCE4 SERIES
DIMENSIONS AND WEIGHTS ADIMENSIONS AND WEIGHTS A
DIMENSIONS AND WEIGHTS ADIMENSIONS AND WEIGHTS A
DIMENSIONS AND WEIGHTS A
T 50 HzT 50 Hz
T 50 HzT 50 Hz
T 50 Hz
DIMENSIONI E PESI SERIE FCE4 4 poli 50 Hz
PUMP TYPE WEIGHT
BHL k
DNA DNM a e h1 h2 x b1 p max kg
FCE4 40-125/02A/A 40 40 70 70 160 160 121 116 140 235 320 416 86 24
FCE4 40-125/02/A 40 40 70 70 160 160 121 116 140 235 320 416 86 24
FCE4 40-160/02/A 40 40 70 70 160 160 121 116 140 235 320 416 86 25
FCE4 40-160/03/A 40 40 70 70 160 160 121 116 140 235 320 416 86 26
FCE4 40-200/05/A 40 40 95 65 220 220 129 163 155 325 440 458 98 44
FCE4 40-200/07/C 40 40 95 65 220 220 128 163 159 325 440 426 98 45
FCE4 40-250/11/P 40 40 95 65 220 220 134 163 174 325 440 493 98 64
FCE4 40-250/15/P 40 40 95 65 220 220 134 163 174 325 440 493 98 65
FCE4 50-125/02/A 50 50 69 73 170 170 121 122 140 236 340 425 88 28
FCE4 50-125/03/A 50 50 69 73 170 170 121 122 140 236 340 425 88 29
FCE4 50-160/05/A 50 50 69 73 170 170 129 122 155 243 340 457 88 31
FCE4 50-200/07/C 50 50 110 73 220 220 128 163 159 326 440 455 100 54
FCE4 50-200/11/P 50 50 110 73 220 220 134 163 174 326 440 522 100 63
FCE4 50-250/15/P 50 50 110 73 220 220 134 163 174 326 440 522 100 66
FCE4 50-250/22/P 50 50 110 73 220 220 168 163 214 331 440 546 100 72
FCE4 65-125/03/A 65 65 77 83 170 170 121 137 140 274 340 444 92 38
FCE4 65-125/05/A 65 65 77 83 170 170 129 137 155 274 340 476 92 42
FCE4 65-160/07/C 65 65 77 83 170 170 128 137 159 274 340 444 92 47
FCE4 65-160/11/P 65 65 77 83 170 170 134 137 174 274 340 511 92 54
FCE4 65-200/15/P 65 65 119 83 237,5 237,5 134 172 174 335 475 527 104 69
FCE4 65-250/22/P 65 65 119 83 237,5 237,5 168 172 214 335 475 551 104 80
FCE4 65-250/30/P 65 65 119 83 237,5 237,5 168 172 214 335 475 582 104 82
FCE4 80-125/07/C 80 80 90 90 175 185 128 148 159 287 360 478 102 51
FCE4 80-125/11/P 80 80 90 90 175 185 134 148 174 287 360 545 102 59
FCE4 80-200/15/P 80 80 130 90 250 250 134 184 174 347 500 554 112 81
FCE4 80-200/22/P 80 80 130 90 250 250 168 184 214 347 500 578 112 87
FCE4 80-200/30/P 80 80 130 90 250 250 168 184 214 347 500 609 112 91
FCE4 80-250/40/P 80 80 130 90 250 250 168 184 214 347 500 654 112 117
FCE4 80-250/55/P 80 80 130 90 250 250 191 184 256 354 500 661 112 125
FCE4 100-160/15/P 100 100 105 105 225 225 134 172 174 311 450 570 117 74
FCE4 100-200/22/P 100 100 140 105 275 275 168 196 214 362 550 599 129 99
FCE4 100-200/30/P 100 100 140 105 225 275 168 196 214 362 550 630 129 101
FCE4 100-250/40/P 100 100 140 105 275 275 168 196 214 362 550 675 129 125
FCE4 100-250/55/P 100 100 140 105 275 275 191 196 256 362 550 682 129 131
FCE4 100-250/75/P 100 100 140 105 275 275 191 196 256 362 550 682 129 141
fc_fce4-4p50-en_g_td
DIMENSIONS (mm)
