FCE4-FCS4 SERIES
HYDRAULIC PERFORMANCE TABLE AT 50Hz, 4 POLES
PUMP
TYPE
l/min 0
l/min 0
50 100
100
150
150
175
175
200
200
300
300
350
350
400
400
500
500
600
600
650
650
750
750
900
900
1100
1100
1200
1200
1500
1500
1800
1800
2000
2000
2500
2500
m
3
/h 0
/h 0
3 6 9 10,5 12 18 21 24 30 36 39 45 54 66 72 90 108 120 150
kW HP
40-125/02A * 0,25 0,33 4,7 4,1 3,3 2,0
40-125/02 * 0,25 0,33 5,9 5,3 4,5 3,3 2,5
40-160/02 * 0,25 0,33 7,1 6,4 5,5 4,3 3,6 2,6
40-160/03 * 0,37 0,5 8,9 8,1 7,2 6,0 5,2 4,4
40-200/05 0,55 0,75 12,4 11,4 10,1 8,2 7,1
40-200/07 0,75 1 14,2 13,2 11,9 10,1 9,1 7,9
40-250/11 1,1 1,5 18,6 17,3 15,7 13,9 12,8 11,6
40-250/15 1,5 2 21,0 19,8 18,2 16,4 15,4 14,3
50-125/02 * 0,25 0,33 6,2 5,5 5,0 4,6 4,3 2,7 1,8
50-125/03 * 0,37 0,5 8,0 7,4 6,8 6,5 6,1 4,4 3,5 2,5
50-160/05 * 0,55 0,75 9,4 8,8 8,2 7,9 7,5 5,9 4,9 3,9
50-200/07 0,75 1 11,4 10,5 9,9 9,5 9,1 7,1 5,6 3,7
50-200/11 1,1 1,5 13,6 12,6 12,0 11,6 11,2 9,2 7,8 5,9
50-250/15 1,5 2 17,0 15,9 15,2 14,8 14,4 12,5 11,4 10,1 7,0
50-250/22 2,2 3 20,2 18,9 18,2 17,8 17,4 15,5 14,3 13,0 10,0
65-125/03 * 0,37 0,5 5,6 4,9 4,3 3,9 3,5 2,6
65-125/05 * 0,55 0,75 6,7 5,9 5,4 5,1 4,7 3,9 2,8 2,2
65-160/07 0,75 1 8,6 7,8 7,2 6,8 6,4 5,4 4,3 3,7 2,4
65-160/11 1,1 1,5 10,4 9,7 9,0 8,6 8,2 7,2 5,9 5,3 3,8
65-200/15 1,5 2 14,7 13,2 12,1 11,6 11,0 9,7 8,1 7,0 4,2
65-250/22 2,2 3 19,0 17,6 16,6 16,0 15,4 14,1 12,7 11,9 10,1 6,5
65-250/30 3 4 21,4 20,1 19,1 18,5 17,9 16,6 15,2 14,4 12,6 9,4
80-125/07 0,75 1 5,6 5,2 5,1 5,0 4,6 4,3 4,1 3,6 2,8 1,6
80-125/11 1,1 1,5 6,8 6,4 6,3 6,2 6,0 5,7 5,5 5,1 4,3 3,1 2,5
80-200/15 1,5 2 10,5 9,6 9,4 9,2 8,7 8,1 7,8 7,1 5,8 3,3
80-200/22 2,2 3 13,7 12,7 12,5 12,3 11,9 11,3 11,0 10,3 9,0 6,8 5,4
80-200/30 3 4 15,8 14,7 14,5 14,3 13,8 13,3 13,0 12,4 11,2 9,3 8,1
80-250/40 4 5,5 19,9 18,7 18,5 18,2 17,7 17,0 16,7 15,9 14,6 12,5 11,2
80-250/55 5,5 7,5 23,2 22,0 21,8 21,5 21,0 20,3 20,0 19,3 18,0 16,0 14,8 10,4
100-160/15 1,5 2 7,8 7,4 7,2 7,1 6,9 6,5 6,0 5,6 4,5 3,0
100-200/22 2,2 3 10,5 9,3 9,2 8,9 8,3 7,5 7,1 5,4 3,5 2,0
100-200/30 3 4 12,8 11,5 11,4 11,1 10,6 9,8 9,3 7,8 5,8 4,3
100-250/40 4 5,5 17,0 15,5 15,3 14,9 14,3 13,4 12,9 11,2 9,2 7,8
100-250/55 5,5 7,5 20,5 19,0 18,8 18,4 17,8 17,0 16,5 14,9 13,1 11,8 8,0
100-250/75 7,5 10 24,0 22,5 22,3 22,0 21,5 20,7 20,3 18,8 17,1 15,8 11,9
* FCE4 VERSION ONLY fce4-fcs4-4p50-en_f_th
Performances according to ISO 9906 - Annex A
RATED
POWER
Q = DELIVERY
H =TOTAL HEAD METRES COLUMN OF WATER
FCE4-FCFCE4-FC
FCE4-FCFCE4-FC
FCE4-FC
S4 SERIESS4 SERIES
S4 SERIESS4 SERIES
S4 SERIES
HYDRAHYDRA
HYDRAHYDRA
HYDRA
ULIC PERFORMANCE TULIC PERFORMANCE T
ULIC PERFORMANCE TULIC PERFORMANCE T
ULIC PERFORMANCE T
ABLE AABLE A
ABLE AABLE A
ABLE A
T 50 Hz, 4 POLEST 50 Hz, 4 POLES
T 50 Hz, 4 POLEST 50 Hz, 4 POLES
T 50 Hz, 4 POLES
