13
Vacuum clamping unit VAC SYS SE
Table of contents
1 Symbols
2 Technical data
3 Machine features
4 Intended use
5 Safety instructions
5.1 General safety instructions
5.2 Machine-related safety instructions
6 Commissioning
6.1 Vacuum pump
6.2 Vacuum clamping unit
7 Operation
8 Maintenance
9 Disposal
10 Accessories
11 Warranty
12 EU Declaration of Conformity
13 Fault correction
1 Symbols
Warning of general danger
Electric shock
Read the operating instructions/
notes
f Advice or tip
The specifi ed illustrations are at the begin-
ning of this operating manual.
2 Technical data
Vacuum pump end pressure abs. 150 mbar
Weight of vacuum clamping
unit SE 1 8.3 kg
Weight of vacuum clamping
unit SE 2 8.1 kg
Protection class
/ II
Holding force of the vacuum clamping
unit
Suction
plate
Holding force
90° tilted
1, 2
(workpiece ver-
tical) [kg]
Holding force
0° tilted
1, 2
(workpiece
horizontal)
[kg]
D 215 55 90
275x100 35 53
200x60 22 30
277x32 21 27
Maximum workpiece dimensions
Suction
plate
Maximum di-
mensions
1
[m]
Maximum
weight
1
[kg]
D 215 1 x 1 30
275x100 1.2 x 0.4 20
200x60 0.8 x 0.2 10
277x32 1.2 x 0.08 8
1
Specifi cations for smooth surfaces such as PMMA (plexi-
glas
®
), PF hard fi bre (Resitex) and worktops, not for MDF
or similar materials.
2
The holding force may decrease by up to 20% over the
course of the years.
Values relate to a vacuum of 85%
(150 mbar end pressure) and include a safety factor of 2.
3 Machine features
[1-1] Mains connection
[1-2] On/off switch
[1-3] Vacuum gauge
[1-4] Ventilation slits
[1-5] Vacuum connection
[2-1] Slide valve
[2-2] Rotary knob for clamping the suction
plate
[2-3] Locking pin for suction plate
[2-4] Clamp lever for tilting fi xture
[2-5] Foot valve
[2-6] Suction plate
4 Intended use
The vacuum clamping unit VAC SYS SE is
designed for clamping objects with fl at,
smooth, airtight surfaces in combination
with vacuum pump VAC SYS VP.
The user bears the responsibility for damage
and accidents caused by improper use.
