Installation, Operation and Maintenance Instruction
Model LER, LERS, LEZ
LER 100-english page 16
Revision 01
Article No 771073302
Issue 01/2010
Weights:
LER, LERS - 2900 min
-
1
Complete unit
Motor power
[kW]
Weight
[kg]
LER(S) 100-125 UN. 402 4,0 75
LER(S) 100-125 UN. 552 5,5 99
LER(S) 100-160 UN. 752 7,5 109
LER(S) 125-160 UNL 3002 30,0 350
LER(S) 125-200 UNL 3002 30,0 350
LER(S) 125-200 UNL 3702 37,0 370
LER(S) 150-200 UNL 3002 30,0 375
LER(S) 150-200 UNL 3702 37,0 395
LER(S) 150-200 UNL 4502 45,0 435
LER(S) 150-250 UNL 5502 55,0 465
LER, LERS - 1450 min
-
1
Complete unit
Motor power
[kW]
Weight
[kg]
LER(S) 200-200 UNL 1104 11,0 315
LER(S) 200-250 UNL 1504 15,0 330
LER(S) 200-250 UNL 1854 18,5 365
LER(S) 200-250 UNL 2204 22,0 380
LER(S) 200-270 UNL 3004 30,0 460
LER(S) 200-315 UNL 3704 37,0 500
LER(S) 250-315 UNL 3704 37,0 610
LER(S) 250-315 UNL 4504 45,0 650
LER(S) 250-315 UNL 5504 55,0 730
LER(S) 250-350 UNL 7504 75,0 870
LER(S) 250-400 UNL 9004 90,0 950
LER(S) 300-350 ULL 11004
110,0 1250
LER(S) 300-400 ULL 11004
110,0 1250
LER(S) 300-450 ULL 13204
132,0 1350
LER(S) 300-480 ULL 16004
160,0 1500
LER, LERS - 970 min
-
1
Complete unit
Motor power
[kW]
Weight
[kg]
LER(S) 200-200 UNL 556 5,5 295
LER(S) 200-250 UNL 556 5,5 295
LER(S) 200-270 UNL 756 7,5 295
LER(S) 200-315 UNL 1106 11,0 295
LER(S) 250-315 UNL 1106 11,0 385
LER(S) 250-315 UNL 1506 15,0 430
LER(S) 250-350 UNL 1856 18,5 505
LER(S) 250-350 UNL 2206 22,0 515
LER(S) 250-400 UNL 3006 30,0 580
LEZ - 2900 min
-
1
Complete unit
Motor power
[kW]
Weight
[kg]
LEZ 100-125 UNN 402 4,0 138
LEZ 100-125 UNN 552 5,5 186
LEZ 100-160 UNN 752 7,5 202
LEZ 125-160 UNL 3002 30,0 705
LEZ 125-200 UNL 3002 30,0 705
LEZ 125-200 UNL 3702 37,0 745
LEZ - 1450 min
-
1
Complete unit
Motor power
[kW]
Weight
[kg]
LEZ 200-200 UNL 1104 11,0 620
LEZ 200-250 UNL 1504 15,0 650
LEZ 200-250 UNL 1854 18,5 720
LEZ 200-250 UNL 2204 22,0 750
LEZ 200-270 UNL 3004 30,0 910
LEZ 200-315 UNL 3704 37,0 990
LEZ 250-315 UNL 3704 37,0 1170
LEZ 250-315 UNL 4504 45,0 1250
LEZ 250-315 UNL 5504 55,0 1410
LEZ 250-350 UNL 7504 75,0 1690
LEZ 250-400 UNL 9004 90,0 1850
LEZ - 970 min
-
1
Complete unit
Motor power
[kW]
Weight
[kg]
LEZ 200 200 UNL 556 5,5 580
LEZ 200 250 UNL 556 5,5 580
LEZ 200 270 UNL 756 7,5 580
LEZ 200 315 UNL 1106 11,0 580
LEZ 250 315 UNL 1106 11,0 720
LEZ 250 315 UNL 1506 15,0 810
LEZ 250 350 UNL 1856 18,5 960
LEZ 250 350 UNL 2206 22,0 980
LEZ 250 400 UNL 3006 30,0 1110
