Lowara LNEEH 40-160/02/S45RCS4 [4/26] Dimensions and weights
![Lowara LNEEH 40-160/02/S45RCS4 [4/26] Dimensions and weights](/views2/1619029/page4/bg4.png)
4
HYDROVAR HVL
IDENTIFICATION CODE
Name [3 digits]
[HVL] = HYDROVAR
®
generation L
Power supply [2 digits]
[2.] = 1~ 208-240 V (50/60 Hz)
[3.] = 3~ 208-240 V (50/60 Hz)
[4.] = 3~ 380-460 V (50/60 Hz)
Rated output power
[3 digits]
kW x 10
Enclosure class (IP class) [1 digit]
[A] = IP55 (Type1)
[B] = reserved for future use
Bus communication [1 digit]
0 = Standard Communication (Modbus, Bacnet)
1 = reserved for future use
2 = reserved for future use
3 = reserved for future use
4 = reserved for future use
5 = reserved for future use
6 = reserved for future use
7 = Wifi Card (option supplied loose)
Optional cards [1 digit]
[0] = no optional cards (as standard)
[1] = Premium Card (option supplied loose)
Display [1 digit]
[0] = reserved for future use
[1] = Internal display installed as standard
Other options [1 digit]
[0] = reserved for future use
H V L 4 . 0 7 5 - A 0 0 1 0
DIMENSIONS AND WEIGHTS
B
H
L
X
WEIGHT
HVL_dim-en_b_td
EXAMPLE: HVL4.075-A0010
HVL=HYDROVAR generation L, 4.=3~ 380-460 V power supply,
075=7,5kW rated output power, A=IP55 (Type1) enclosure class,
0=Standard Bus communication, 0=no optional card,
1=internal display installed, 0=no other options installed.
NOTE: HYDROVAR output voltage is three phase.
