5
EMC requirements
HYDROVAR fulfills the product standard EN61800-3:2004 + A1:2012, which defines categories (C1 to C4) for device
application areas.
Depending on the motor cable length, a classification of HYDROVAR by category (based on EN61800-3) is reported
in the following tables:
HYDROVAR HVL
EMC COMPATIBILITY
HVL
HYDROVAR classification by
categories based on EN61800-3
2.015 ÷ 2.040 C1 (*)
3.015 ÷ 3.110 C2 (*)
4.015 ÷ 4.220 C2 (*)
(*) 0,75 motor cable length; contact Xylem for further information
En-Rev_A
CARD
Premium Card HYDROVAR
For the e-LNE..H and e-LNT..H series, the Premium Card
comes fitted as standard on the standalone HYDROVAR.
This allows to control up to five fix speed pumps via an
external panel.
The Premium Card will allow additional features listed
below:
• 2 additional Analog Inputs
• 2 Analog Outputs
• 1 additional digital input
• 5 relays.
Wi-Fi Card HYDROVAR (optional)
With the WiFi card fitted in the Hydrovar, the unit can will
allow you to be connected to a wireless network.
Sensors
The following sensors are available for HYDROVAR:
a. Pressure-transducer
b. Differential pressure-transducer
c. Temperature-sensor
d. Flow indicator (orifice plate, inductive flow meter)
e. Level-sensor.
OPTIONAL COMPONENTS
