4. Overview of the TV set

Rear View

Item Description

1 VGA IN

Connect a 15-pin D-sub RGB cable to the RGB output of your

computer and the other end to the RGB input on the rear of the LED

TV.

2 PC Audio input

Connect the RGB Audio Out on your computer to the RGB Audio on

the rear of the LED TV.

3 AV OUT(CVBS/L/R) Connect a external device to the composite AV OUT in jacks.

4 RF Connect this jack to your Cable or VHF/UHF antenna.

5 HDMI Input Terminal Connect this port to the HDMI output of A/V device.

6 COAX OUT Connects to the coaxial audio input of your digita stereo equipment.

7 MINI AV IN

Connect a external device to the composite VIDEO(V) and

AUDIO(L/R) out jacks on most video equipment.

*L/R (Audio in) is sharing with YPbPr.

8 MINI YPbPr IN Connect this port to the YPbPr output of A/V device.

9 CI SLOT

Used to insert a CI card. A CI card allows you to view all the

channels that you subscribe to.For more information, see

“Conditional Access”section.

10 USB

11 EARPHONE

Connect to your earphones. By connecting the earphones, you can

listen to the sound from the TV on headphones.

*If you connect the earphones,the TV speakers will be muted.

Connect to your USB devices, such as USB ash drive.
