SENA SMH5 [6/38] Package contents

SMH5

2. PACKAGE CONTENTS

• Headset Main Unit

Jog Dial

LED

•Charging LED

Phone Button

DC Power Charging & Firmware Upgrade Port

• Microphone Sponges

• Microphone

• Clamp Unit

• Helmet Speakers

- Basic Kit

• Attachable Boom Microphone

• Hook and Loop Fastener for Boom Microphone

• Attachable Boom Microphone Holder

• Hook and Loop Fastener for Boom Microphone Holder
