FLIR f=17 mm. (24°) [3/3] Mechanical drawings

0.73in

18.7mm

1.69in

42.9mm

2.25in

57mm

Lens IR f=10mm (42°)

Lens IR f=17mm (24°)

Lens IR f=29mm (14°)

R&D Instruments

Modified

Rev

A

1:1
